80 Watt Square Explosion Proof Fixture | 11200 Lumens | Class 1 Division 1 | 5000K | 100V-277V

SKU: MLLG-E-LED-EXPLD-80-50-C1D1 | Web ID: 1280

Product Alternatives

Watts:

80

Lumens/Watt:

140

Replaces:

250 Watt Metal Halide

Dimmable:

No

Beam Angle:

120° (std) Special Order: 40° 60° 90°

Housing:

Copper Free Aluminum

Mounting:

Yoke | 3/4 in NPT Pendant

Dimensions:

11.6 in x 11.6 in x 9.57 in

Warranty:

5 years

Rated Life:

50,000 (L70) hours

Icons Doc Led Select White
View Full Spec Sheet
Retail Price:$819.83
Get Contractor or Bulk Pricing

147 in stock

    Product total

    Options total

    Sub-Total

    Inventory Count: 147
    Availability:In Stock | Ships In:4-7 Business Days
    Product Description
    ETLRebatesC1D1IP66IK10

    80 Watt LED Explosion Proof Fixture – Class 1 Division 1 produces 11200 lumens at 140 lumens / watt replacing 250 Watt Metal Halide. Fixture can work as both a high bay / low bay or flood light. It comes with either 100V-277V LED driver. Color temperature is 5000K. Choose between 120° (std) Special Order: 40° 60° 90° beam angles. This fixture comes with the Yoke or 3/4 in NPT Pendant mount. Fixture can be angled if required. Fixture is IP66 wet location rated as well as Impact Rated at IK10, the strongest rating available. This fixture can operate in temperature conditions between -40°F to +140°F. Built-in 10KvA surge protection.

    UL844 Certifications

    Class 1 Division 1, Group C,D

    Class 1, Division 2, Groups A,B,C,D

    Class 2, Division 1, Groups E,F,G

    Class 2, Division 2, Groups F,G

    Class 3

    Zones: 1/2, 21/22

    Wet Locations (UL 1598), UL844, CSA, ATEX, IECEX

    Full Product Specification

    Watts:

    80

    Lumens:

    11200

    Lumens/Watt:

    140

    Replaces:

    250 Watt Metal Halide

    Color Temp:

    5000K

    CRI:

    70+

    IP Rating:

    IP66

    IK Rating:

    IK10

    Input Voltage:

    100V-277V

    Surge Protection:

    10KvA

    Operating Temp:

    -40°F to +140°F

    Rated Life:

    50,000 (L70) hours

    Dimmable:

    No

    Beam Angle:

    120° (std) Special Order: 40° 60° 90°

    Optics:

    Tempered Glass Lens

    Frequency:

    50-60Hz

    Power Factor:

    >.95

    THD:

    < 10%

    Housing:

    Copper Free Aluminum

    Fixture Color:

    Gray

    Mounting:

    Yoke | 3/4 in NPT Pendant

    Dimensions:

    11.6 in x 11.6 in x 9.57 in

    Weight:

    26.9

    Warranty:

    5 years
