200 Watt Square Explosion Proof LED Light | 28000 Lumens | Class 1 Div 2 | 5000K | 100V-277V or 277V-480V
Dwayne Kula | President, CTO and Founder
Product Specifications
UL Specs
- UL 844 Hazardous Locations
- Class I, Division 2, Groups A, B, C, D
- Class II, Division 1, Groups E, F, G
- Class II, Division 2, Groups F, G
- Class III
- UL 1598 Suitable for Wet Locations
- UL 1598A Marine Outside Type
- ABS
ATEX Marking
| II 2 G Ex eb mb IIC T5…T6 Gb | |
| II 2 D Ex tb IIIC T80°C…T100°C Db |
IECEx Marking
| Ex eb mb IIC T5…T6 Gb | |
| Ex tb IIIC T80°C…T100°C Db |
Key Features
| Brand | LED Lighting Supply |
| Watts | 200 |
| Lumens | 28000 |
| Lumens Per Watt | 140 |
| Replaces | 400 Watt Metal Halide |
| Voltage | 100V-277V or 277V-480V |
| Color Temperature | 5000K |
| CRI | 70+ |
| Dimming | 1-10V |
| Beam Angles (Std) | 120° |
| Beam Angles (Opt) | 40° or 60° or 90° |
| Optics | Tempered Glass Lens |
| Lifespan | 50,000 (L70) hours |
| Mounting | Yoke or 3/4 in NPT Pendant |
| Fixture Color | Gray |
| Frequency (Hz) | 50-60Hz |
| Power Factor | >.95 |
| THD | < 10% |
Durable Construction
| Housing | Copper Free Aluminum |
| IP Rating | IP66 |
| IK Rating | IK10 |
| Surge Protection | 10kV |
| Operating Temperature | -40°F to 122°F |
| Certifications | ETL | Rebate Eligible |
| Warranty | 5 years |
Measurements
| Dimensions (in) | 19 X 9 X 7.4 |
| Weight (lbs) | 26 |
Product SKU Variations
- SKU: MLLG-E-LED-EXPLA-200-50-C1D2
- SKU: MLLG-E-LED-EXPLA-200-50-HV-C1D2
Product Lighting Layout Estimator
Use this estimator to calculate approximate fixture count, spacing, and average foot-candles for a simple rectangular space using the selected LED fixture. Enter your room dimensions, mounting height, target foot-candles, light loss factor, and room/layout condition to generate a preliminary lighting layout. When IES photometry is available, workplane height and room reflectance controls are shown.
Project Inputs
Estimated Results
Estimated average foot-candles are preliminary and should be verified with a lighting plan for project-critical applications.
Room / Layout Condition: This field is used only when usable IES photometry is not available. In fallback mode, it acts as a simplified room utilization factor for reflectance, fixture distribution, racking, obstructions, and how much fixture light reaches the work area. Open / light-colored spaces use 0.90, typical warehouses or shops use 0.75, racked or obstructed spaces use 0.60, and dark or complex spaces use 0.45. When IES photometry is active, this field is hidden and the estimator uses the selected workplane height, LLF, and simplified reflectance adjustment instead.
Photometry / Simulation Note: When usable IES photometry is available for the selected fixture, this estimator uses the fixture’s IES candela data, selected workplane height, light loss factor, and simplified reflectance adjustment to estimate fixture count, average foot-candles, and visual light distribution. The reflectance adjustment is a conservative approximation and is not a full zonal-cavity, radiosity, or professional photometric room calculation. When IES photometry is not available, the estimator uses a simulated beam model based on lumens, mounting height, room/layout condition, light loss factor, and beam angle.
Preliminary Estimate Only: This estimator is intended for simple square or rectangular spaces and should be used as a planning aid, not a final photometric lighting plan. Actual light levels may vary based on fixture optics, selected IES file, mounting conditions, workplane height, ceiling height, surface reflectance, obstructions, controls, voltage, installation conditions, and site-specific requirements. Project-critical applications should be verified with a formal lighting plan.
This estimate is a starting point. Warehouses, industrial facilities, hazardous locations, sports areas, schools, healthcare spaces, public areas, and code-sensitive projects may require a reviewed lighting layout before purchase or installation.
Product Overview
The 200 Watt Square Explosion Proof LED Light is engineered for environments where safety and durability are paramount. Designed to deliver 28,000 lumens at a color temperature of 5000K, this fixture is suitable for hazardous locations, including Class I, Division 2 areas. It operates efficiently across a voltage range of 100V-277V or 277V-480V, making it versatile for various industrial applications.
This fixture is particularly effective as a replacement for 400 Watt Metal Halide lights, offering significant energy savings and reduced maintenance. Its robust construction and certifications, including UL 844 and UL 1598A Marine, ensure reliable performance in challenging conditions such as paint booths and chemical processing facilities.
Core Performance and Output
With an output of 28,000 lumens, this explosion-proof LED light provides high-efficiency illumination at 140 lumens per watt. The fixture offers multiple beam angles, including 120°, 40°, 60°, and 90°, allowing for tailored light distribution based on specific needs. Electrical performance is optimized with a power factor greater than 0.95 and a THD of less than 10%.
While the fixture is suitable for a range of mounting heights, excessive output at low heights may lead to increased glare. It is important to consider the beam angle and mounting height to ensure optimal uniformity and coverage.
Adjustability and Control Options
This fixture supports 1-10V dimming, providing flexibility in light output to match varying operational requirements. The dimming capability allows for energy savings and enhanced control over the lighting environment, particularly in areas where light levels need to be adjusted frequently.
Mounting options include yoke or 3/4 inch NPT pendant, offering adaptability to different installation scenarios. This flexibility ensures that the fixture can be securely installed in a variety of hazardous locations.
Longevity and Reliability
Designed for a lifespan of 50,000 hours (L70), this LED fixture minimizes maintenance needs and ensures long-term reliability. The robust construction and high-quality components contribute to its durability, even in harsh environments.
With a 5-year warranty, the fixture provides peace of mind, ensuring that it will perform consistently over its operational life. The inclusion of surge protection up to 10kV further enhances its reliability in areas prone to electrical disturbances.
Build Quality and Physical Characteristics
The fixture is constructed from copper-free aluminum, providing excellent resistance to corrosion and ensuring longevity in marine and industrial environments. Its IP66 and IK10 ratings confirm its suitability for wet locations and its ability to withstand physical impacts.
Measuring 19 x 9 x 7.4 inches and weighing 26 pounds, the fixture is compact yet robust, allowing for easy installation and integration into existing systems. The gray finish offers a neutral aesthetic that blends well with industrial settings.
Where This Product Fits Best
This explosion-proof LED light is ideal for environments where safety and durability are critical. It is particularly suited for hazardous locations and areas with potential exposure to explosive gases or dust.
- hazardous location lighting
- explosion proof lighting
- paint booth lighting
- chemical processing facility lighting
- oil and gas facility lighting
- refinery lighting
The fixture’s environmental characteristics, including its ability to operate in temperatures ranging from -40°F to 122°F, make it suitable for both indoor and outdoor applications in harsh conditions.
Installation and Long-Term Use
Installation is straightforward with options for yoke or pendant mounting, allowing for flexibility in various settings. The fixture’s design facilitates easy integration into existing systems, reducing installation time and complexity.
For long-term use, regular inspection and cleaning are recommended to maintain optimal performance, especially in environments with high levels of dust or corrosive substances. The fixture’s robust construction minimizes the need for frequent maintenance.
How This Fixture Is Commonly Used
This fixture is commonly mounted at heights that optimize its light distribution and minimize glare. Typical mounting heights range from 10 to 30 feet, depending on the specific application and required light levels.
Spacing and layout patterns vary based on the beam angle and desired light intensity. Higher output settings can reduce the number of fixtures needed but may require careful consideration of glare and uniformity.
Safety, Certifications, and Warranty
This LED light is certified for use in hazardous locations, meeting UL 844, Class I/II/III standards, and is suitable for wet locations as per UL 1598. It also holds ATEX and IECEx certifications, ensuring compliance with international safety standards.
The fixture is backed by a 5-year warranty, providing assurance of its quality and reliability. Its robust design and certifications make it a dependable choice for challenging environments.
Frequently Asked Questions
Q: What is the beam angle of this fixture?
A: The standard beam angle is 120°, with optional angles of 40°, 60°, and 90° available.
Q: Can this fixture be used in marine environments?
A: Yes, it is UL 1598A Marine certified, making it suitable for marine environments.
Q: What is the operating temperature range?
A: The fixture operates effectively in temperatures from -40°F to 122°F.
Q: How does the dimming function work?
A: The fixture supports 1-10V dimming, allowing for adjustable light output to suit different needs.
Q: What is the warranty period for this fixture?
A: The fixture comes with a 5-year warranty.
Application Questions and Clarification
Q: Is this fixture suitable for paint booth lighting?
A: Yes, it is designed for use in paint booths and other hazardous locations.
Q: Can this fixture be used in oil and gas facilities?
A: Yes, it is suitable for oil and gas facility lighting, meeting necessary safety standards.
Q: What mounting options are available?
A: The fixture can be mounted using a yoke or 3/4 inch NPT pendant.
Q: What are the typical applications for this fixture?
A: Typical applications include hazardous location lighting, explosion proof lighting, and chemical processing facility lighting.
