Commercial Lighting Layout & Design

Get Your Custom Lighting Plan With Product Recommendations

Includes up to 8% off the price of our recommended lighting products

What to expect when Requesting a lighting plan?

A Lighting Expert Reviews Your Request

We Follow Up to Gather Project Details

Custom Lighting Plan With Product Recommendations is Created

Review and Approve Your Lighting Design

Purchase the Recommended Products

Our Customers

CBRE needed high quality lighting for their customer, with stock available for ongoing projects.

Customer had an urgent need for high temperature lights. We had them in stock & shipped out next day.

Poor lighting caused parking lot safety issues for spectators. Our lighting plan & new lights resulted in an improved experience.

Customer needed to source large quantities of specialty fixtures for use in their manufactured products.

Tracy Electric was seeking a reliable source for ongoing lighting projects.

Distributors partner with us to provide customers a high quality product at a reasonable price.

Repeat lighting supplier for an electrical contractor working in manufacturing facilities.

Permanent tent lighting for large acrobatics facility. Our lighting plan & recommendations resulted in ideal performer & spectator safety.

A commercial lighting plan is essential for achieving the right balance of brightness, energy efficiency, and safety in your facility. A well-designed plan helps you determine the ideal fixture types, placement, and light levels for your specific application-whether it is an office, warehouse, or retail space. By understanding layout, spacing, and recommended foot-candle levels, you can make informed decisions that maximize performance and minimize long-term costs.

Commercial Lighting Design by Project Type

Frequently Asked Questions

What Is Commercial Lighting Design?

Commercial lighting design is the process of creating a detailed plan for lighting indoor and outdoor commercial spaces. Using photometric modeling, we map your space and strategically place fixtures to achieve target brightness levels (measured in foot candles) and optimal light distribution. This ensures your facility meets performance, safety, and efficiency goals before installation.

What Should an Ideal Commercial Lighting Layout Include?

An effective layout specifies fixture types, quantities, and mounting locations, and provides a visual map of light levels across your space. It should also include light balance calculations for different work zones and, where relevant, energy savings projections to help you select the most efficient solution for your needs.

Commercial Workshop with LED Lighting Supply Lights

What Are the Most Important Factors in Commercial LED Lighting Design?

Key factors include the purpose of each area, required light levels, fixture selection, and energy efficiency. For exterior spaces, weather-resistant fixtures and proper coverage for safety are critical. For interiors, selecting the right color temperature (typically 3000K to 5000K) and ensuring even light distribution are essential for productivity and comfort.

What Are Standard Commercial Lighting Requirements?

Lighting requirements vary by application. For example, offices typically require 30-50 foot candles, while warehouses may need 20-60 foot candles depending on tasks. Each design is tailored to your industry and operational needs to ensure compliance and optimal performance.

How Do You Calculate Lighting Requirements for Commercial Spaces?

We use photometric modeling software to analyze your space dimensions, ceiling heights, and intended use. This approach determines the precise fixture count, types, and mounting positions needed to achieve your target illumination levels and uniformity.

How Many Foot Candles Do Commercial Spaces Need?

Foot candle requirements depend on your space’s function and industry guidelines. Office environments, warehouses, and retail spaces all have different needs. Our lighting experts can recommend the right foot candle levels for your application to support productivity and safety.

How Much Can a Commercial Lighting Plan Save on Energy Costs?

A professional lighting plan can deliver significant energy savings compared to traditional lighting. By optimizing fixture placement and selecting the right wattages, we help eliminate over-lighting and dark spots. Our plans also identify potential utility rebates and provide ROI calculations, often showing payback periods of 2-4 years through reduced energy consumption.

Do I Need a Lighting Plan Before Purchasing Commercial LED Fixtures?

For any commercial project over 5,000 square feet or with a substantial investment, a lighting plan is highly recommended. Proper planning ensures you purchase the correct fixture types and quantities, achieve code compliance, and avoid costly mistakes or inadequate coverage after installation.

How Long Does It Take to Complete a Commercial Lighting Design?

Most commercial lighting designs are completed within 5-10 business days, depending on project complexity. We require basic space dimensions, ceiling heights, and intended use to start. More complex or multi-zone projects may take 2-3 weeks for thorough analysis and design iterations.

What Information Do You Need to Create My Lighting Plan?

We need floor plans or space dimensions, ceiling heights, and details about your current lighting if available. Photos, electrical panel locations, and any special requirements help us create a more accurate design. For new construction, architectural drawings and intended occupancy schedules are also helpful for optimal lighting placement and controls.

How Many Foot Candles Do You Need for Commercial Lighting?

The required foot candle level depends on the specific use of your commercial space. Office settings, warehouses, and retail areas all have different lighting needs. Our experts can help you determine the best option for your application.

How Many Lights Do I Need for My Commercial Space?

The number of fixtures required depends on your space’s size, ceiling height, and target foot candle level. A professional lighting plan calculates the optimal quantity and placement to ensure even coverage and avoid over- or under-lighting.

What Mounting Height Should I Use for Commercial Lighting?

Mounting height is determined by your ceiling height and the type of fixture selected. High bay fixtures are typically used for ceilings above 20 feet, while low bay or panel lights are suitable for lower ceilings. Proper mounting height ensures effective light distribution and minimizes glare.

How Far Apart Should Commercial Fixtures Be Spaced?

Fixture spacing is based on fixture output, mounting height, and the desired uniformity. Even spacing helps prevent shadows and dark spots. A lighting plan will specify the ideal spacing for your application to achieve consistent illumination.

What Type of Fixtures Are Best for Commercial Applications?

The best fixture type depends on your environment and lighting goals. High bays are ideal for warehouses and industrial spaces, while panels or troffers work well in offices. Outdoor areas may require wall packs or flood lights. Selecting the right fixture ensures durability, efficiency, and proper light levels.

How Do I Reduce Shadows or Dark Spots in My Commercial Space?

To minimize shadows and dark spots, use a combination of proper fixture placement, adequate overlap of light patterns, and the right fixture type for your ceiling height and layout. A photometric lighting plan will identify and address potential problem areas before installation.

Do I Need a Custom Lighting Plan for My Project?

If your space has unique requirements, irregular layouts, or specific lighting goals, a custom lighting plan ensures you achieve the best results. Custom plans address challenges such as high ceilings, obstructions, or specialized tasks, providing tailored solutions for your facility.
