300 / 240 / 200 Watt LED Parking Lot Light | up to 51000 Lumens | 3000K / 4000K / 5000K | 100V-277V or 277V-480V | Type 3 | Built-in Photocell

Product Overview

This LED parking lot light offers field-adjustable wattage settings of 300, 240, or 200 watts, delivering up to 51,000 lumens at maximum output. The fixture is designed to replace 400 or 1000 watt metal halide systems in outdoor area lighting applications.

The standard Type 3 optic provides lateral light distribution suitable for parking lots and similar open areas. The fixture features a built-in photocell for dusk-to-dawn operation and a selectable color temperature switch with 3000K, 4000K, and 5000K options.

It is constructed with a die-cast aluminum housing in a dark bronze finish. The fixture supports both 100V-277V and 277V-480V input ranges and includes a dimmable driver.

Mounting options include yoke, arm, slip fitter, or trunnion brackets for pole, post, or wall installation. The fixture is IP66 rated for wet locations and operates in ambient temperatures from -4°F to +122°F.

Where This Product Fits Best

This fixture is designed for outdoor parking lots, drive lanes, and perimeter areas where wide lateral light distribution is required. The Type 3 optic is suited for illuminating rectangular spaces and lot layouts.

It is appropriate for facilities upgrading from 400 or 1000 watt metal halide fixtures, especially where field-adjustable wattage and color temperature are needed to match existing site conditions or lighting requirements.

The IP66 rating allows use in environments exposed to rain, snow, and washdown. The fixture is compatible with both standard and high-voltage electrical systems, supporting a range of commercial and industrial sites.

Mounting flexibility supports installation on new or existing poles, posts, or building walls using the specified bracket types.

Performance and Functional Considerations

The wattage adjustment feature allows selection between 300, 240, or 200 watt settings, providing control over light output and energy use. Maximum output is 51,000 lumens at 170 lumens per watt.

The onboard color temperature switch enables selection of 3000K, 4000K, or 5000K to match site preferences or requirements. The built-in photocell supports automatic dusk-to-dawn operation without additional external controls.

The fixture is compatible with both 100V-277V and 277V-480V input voltages, supporting a wide range of electrical systems. The dimmable driver allows integration with compatible dimming controls if required.

The die-cast aluminum housing provides durability in outdoor environments. The IP66 rating ensures protection against water ingress during heavy rain or washdown events.

Installation and Long-Term Use

The fixture supports multiple mounting methods: yoke, arm, slip fitter, or trunnion brackets. This allows installation on round or square poles, posts, or directly to building walls, depending on site requirements.

All adjustments for wattage and color temperature are made on the fixture using onboard switches. The built-in photocell is pre-installed and does not require separate wiring or setup.

The fixture operates reliably in ambient temperatures from -4°F to +122°F. The die-cast aluminum housing resists corrosion and impact in outdoor environments.

Routine maintenance is limited to periodic cleaning of the lens and housing as needed for site conditions. No lamp or ballast replacements are required.

How This Fixture Is Commonly Used

After installation, you can adjust the wattage and color temperature directly on the fixture using the onboard switches. This allows you to fine-tune light levels and appearance to match site needs or user preferences without removing the fixture from its mounting location.

The built-in photocell enables automatic dusk-to-dawn operation, so the fixture turns on and off based on ambient light conditions. No additional controls or timers are needed for standard operation.

Once set, the fixture operates with minimal user interaction. The IP66 rating means you do not need to take extra precautions during routine exterior cleaning or in wet weather.

The fixture?s mounting options allow you to reposition or reorient the light as site layouts change, using the appropriate bracket for the new mounting surface.

Safety, Certifications, and Warranty

This fixture is IP66 rated for wet locations. It is suitable for outdoor use in environments exposed to rain, snow, or washdown.

The die-cast aluminum housing provides physical durability for long-term exterior installation.

This fixture is ETL listed and DLC Premium qualified.

LED Lighting Supply provides a 5-year warranty on this fixture.

Frequently Asked Questions

What voltage ranges are supported? This fixture operates on 100V-277V or 277V-480V input.

What is the maximum light output? The fixture delivers up to 51,000 lumens at the 300 watt setting.

What mounting options are available? The fixture can be mounted using yoke, arm, slip fitter, or trunnion brackets for pole, post, or wall installation.

What certifications does this fixture carry? This fixture is ETL listed and DLC Premium qualified.

What is the environmental rating? The fixture is IP66 rated for wet locations and operates from -4°F to +122°F.

What is the warranty period? LED Lighting Supply provides a 5-year warranty on this fixture.

Application Questions and Clarification

This product description reflects the provided specifications, ratings, and configuration options. For questions related to site-specific conditions, electrical compatibility, control integration, or application requirements not addressed in the provided data, our team is available to provide clarification.
