50 Foot Stadium Light Pole | 1 Cross Arm | 115 MPH Wind Rating

Product Overview

The 50 Foot Stadium Light Pole with 1 Cross Arm is a steel pole system designed for mounting high-output sports and area lighting fixtures at elevated heights. This pole is engineered for stadium and athletic field environments where tall mounting positions are required to achieve wide-area illumination and minimize glare for players and spectators. The pole is fabricated from 8 gauge S235 steel, hot dip galvanized for corrosion resistance, and includes an anchor base for secure foundation installation. The 10-foot cross arm provides a mounting platform for multiple fixtures, supporting typical stadium lighting layouts.

This configuration is suitable for new construction or retrofit projects where 50-foot mounting heights are needed to deliver uniform light distribution across large outdoor sports fields or stadiums. The 115 mph wind load rating addresses structural requirements for open, exposed sites. This pole is commonly specified for athletic complexes, municipal sports fields, and commercial stadiums.

Core Performance and Output

This pole supports a total mounting height of 50 feet, allowing for broad light coverage and reduced shadowing on large fields. The 8 gauge S235 steel construction provides structural integrity for supporting multiple high-wattage LED or HID fixtures, with a cross arm length of 10 feet to accommodate wide fixture spacing. The 115 mph wind load rating ensures compliance with most regional codes for open-area installations, including stadiums and athletic fields.

The anchor base design with 8 anchor bolts (43 inches long, 1.18 inches diameter) delivers secure attachment to concrete foundations. The pole?s top diameter of 5.91 inches and base diameter of 17.71 inches are sized for stability and fixture mounting compatibility. Excessive fixture weight or EPA (Effective Projected Area) beyond the pole?s structural limits may require alternate configurations or additional engineering review.

Adjustability and Control Options

The included 10-foot cross arm provides flexibility for fixture positioning, allowing for tailored aiming and spacing to meet specific lighting requirements. The cross arm supports multiple fixtures, enabling various beam angles and coverage patterns. Fixture orientation and tilt can be adjusted during installation to optimize light distribution for the field or stadium layout.

This pole does not include integrated electrical controls or wiring provisions; fixture-level controls and wiring must be specified separately. The pole?s design accommodates standard sports lighting fixtures with compatible mounting hardware.

Longevity and Reliability

The hot dip galvanized finish protects the steel pole from corrosion, extending service life in outdoor environments exposed to weather and moisture. S235 steel provides high strength and durability for long-term structural performance. The anchor base and bolt configuration are designed for stability under wind loading and fixture weight.

Routine inspection of the pole, anchor bolts, and cross arm connections is recommended to maintain structural integrity over time. The 1-year warranty covers material and manufacturing defects under normal use conditions.

Build Quality and Physical Characteristics

This pole is constructed from 8 gauge S235 steel, providing a balance of strength and manageable weight for handling and installation. The hot dip galvanized finish offers uniform corrosion protection across all surfaces, including welds and hardware interfaces. The pole weighs 850 lbs and is designed for crane or lift-assisted installation.

The anchor base design allows for secure attachment to engineered concrete foundations. The 10-foot cross arm is welded or bolted to the pole, supporting multiple fixtures and enabling wide-area coverage. All dimensions and hardware are sized for compatibility with standard stadium lighting fixtures and mounting accessories.

Where This Product Fits Best

This 50-foot steel light pole is intended for large-scale outdoor environments where elevated lighting is required for safety, visibility, and uniformity. It is most often used in:

• sports facility lighting
• area lighting
• commercial site lighting
• parking lot lighting
• roadway lighting
• campus lighting
• industrial yard lighting
• dealership lighting

The pole?s wind load rating and galvanized finish make it suitable for exposed sites, including stadiums, athletic fields, and large commercial or industrial properties. It is not intended for low-mount or small-area applications due to its height and structural capacity.

Installation and Long-Term Use

Installation requires a properly engineered concrete foundation with 8 anchor bolts set to the specified pattern and depth. The pole is lifted into position using a crane or lift, then secured to the anchor base. The cross arm is attached prior to or after pole erection, depending on site logistics and fixture mounting requirements.

All fixture wiring, aiming, and commissioning are performed after pole installation. Periodic inspection of anchor bolts, base plate, and cross arm connections is recommended to ensure ongoing structural performance. Galvanized surfaces should be checked for coating integrity, especially in coastal or corrosive environments.

How This Fixture Is Commonly Used

Typical mounting height is 50 feet, supporting wide-area lighting layouts for stadiums, sports fields, and large parking lots. Fixture spacing on the cross arm is determined by the number and type of luminaires, EPA limits, and required light levels. Poles are commonly spaced around the perimeter of the field or site, with layout patterns based on field dimensions and lighting uniformity targets.

Higher mounting heights reduce glare and improve uniformity but may require higher wattage fixtures to achieve target light levels. Fixture count and aiming should be coordinated with lighting design to balance coverage, uniformity, and energy use.

Safety, Certifications, and Warranty

The pole is manufactured from S235 steel and finished with hot dip galvanizing for corrosion resistance. It is engineered for a 115 mph wind load rating. All hardware and anchor bolts are sized for structural safety in accordance with typical stadium and area lighting standards.

This product includes a 1-year warranty covering material and manufacturing defects. No additional certifications are specified for this pole.

Frequently Asked Questions

Q: What is the maximum wind speed this pole is rated for?

A: The pole is rated for wind loads up to 115 mph.

Q: How many fixtures can be mounted on the cross arm?

A: The 10-foot cross arm can support multiple fixtures, subject to total EPA and weight limits for the pole and arm.

Q: What type of foundation is required for installation?

A: A reinforced concrete foundation engineered for the pole?s height, weight, and wind load is required. Anchor bolts must be set to the specified pattern and depth.

Q: Is the pole finish suitable for coastal environments?

A: The hot dip galvanized finish provides corrosion resistance, but additional coatings may be needed for highly corrosive or coastal sites.

Q: How should fixture spacing and aiming be planned on this pole?

A: Fixture spacing and aiming depend on the lighting design, EPA limits, and required light levels. Coordination with a lighting designer is recommended for optimal results.

Application Questions and Clarification

Q: Can this pole be used for both sports facility lighting and parking lot lighting?

A: Yes, this pole is suitable for both sports facility lighting and large parking lot lighting where 50-foot mounting heights are appropriate.

Q: Is this pole compatible with LED sports lighting fixtures?

A: The pole and cross arm are compatible with most LED sports lighting fixtures that meet the mounting and EPA requirements.

Q: Are there restrictions on the number of fixtures due to wind load?

A: Yes, the total number and size of fixtures are limited by the pole?s wind load and EPA rating. Exceeding these limits may require a different pole configuration.

Q: What maintenance is required for long-term reliability?

A: Periodic inspection of anchor bolts, base plate, cross arm connections, and galvanized surfaces is recommended to maintain structural integrity and corrosion protection.
