10 Foot Round Steel Light Pole | 3 Inch Diameter | Anchor Base

Product Overview

The 10 Foot Round Steel Light Pole with a 3 Inch Diameter and Anchor Base is designed for mounting area, roadway, and site lighting fixtures in commercial and light industrial environments. This pole is fabricated from 11 gauge steel, hot dip galvanized and powder coated for corrosion resistance. The anchor base design supports straightforward installation on concrete foundations using standard anchor bolts. Typical use cases include parking lot lighting, low-height roadway lighting, and site perimeter illumination where a 10-foot mounting height is appropriate.

This pole is supplied with a bronze finish and includes a top cap. It is engineered for environments where moderate mounting heights are required and where wind load and fixture EPA must be considered for safe, long-term operation.

Core Performance and Output

This 10-foot steel pole supports fixture mounting at a height suitable for small parking lots, drive lanes, and pedestrian areas. The 3-inch diameter and 11 gauge wall thickness provide structural integrity for mounting single or dual fixtures within the EPA and weight limits. EPA ratings are 26.2 at 70 mph, 22.5 at 80 mph, 20.1 at 90 mph, 16.4 at 100 mph, 11.3 at 110 mph, and 9.6 at 120 mph. These values define the maximum allowable effective projected area of fixtures and brackets at each wind speed.

Structural performance is optimized for low to moderate wind zones and for fixtures with a combined EPA and weight within the specified limits. At 10 feet, excessive fixture EPA or mounting multiple large fixtures can exceed wind load ratings. This pole is not intended for high-mast or high-output area lighting applications.

Adjustability and Control Options

This pole is designed for fixed mounting of lighting fixtures using standard tenon or direct-mount hardware. The anchor base allows for precise vertical alignment during installation. No integrated tilt, rotation, or height adjustment features are included.

Control options depend on the fixture and bracket selected. The pole itself does not include integrated wiring, control boxes, or sensor mounting provisions. Conduit entry and wiring access are provided through the base plate and handhole as required for typical area lighting installations.

Longevity and Reliability

The pole is constructed from 11 gauge steel and finished with hot dip galvanizing and a powder coat layer for corrosion resistance. This combination provides long-term durability in outdoor environments, including exposure to rain, snow, and UV.

Routine inspection of the anchor bolts, base plate, and finish is recommended to maintain structural integrity. The included top cap prevents water ingress at the pole top, reducing internal corrosion risk. The pole is covered by a 1-year warranty.

Build Quality and Physical Characteristics

This pole measures 10 feet in total height with a 3-inch outside diameter and weighs 72 lbs. The anchor base features an 8-inch bolt circle and 2.75-inch bolt projection, compatible with standard anchor bolt patterns for commercial lighting poles. The bronze powder coat finish is applied over hot dip galvanizing for enhanced corrosion protection.

The pole is supplied with a top cap and is designed for use with area, roadway, and site lighting fixtures that do not exceed the EPA and weight limits. The 11 gauge wall thickness provides rigidity for low-height installations in moderate wind zones.

Where This Product Fits Best

This 10-foot steel pole is suited for environments requiring low to moderate mounting heights and where wind load and EPA limits are within the specified range. It is commonly used in small parking lots, site perimeters, and low-height roadway or drive lane lighting. The finish and construction are suitable for standard commercial and light industrial exterior settings.

• parking lot lighting
• area lighting
• roadway lighting
• commercial site lighting
• campus lighting
• industrial yard lighting
• dealership lighting
• sports facility lighting

The pole is intended for use in environments where mounting heights do not exceed 10 feet and where fixture EPA and weight are within the published wind load ratings. Not suitable for coastal or highly corrosive environments without additional protective measures.

Installation and Long-Term Use

Installation requires a concrete foundation with anchor bolts set to match the 8-inch bolt circle and 2.75-inch projection. The anchor base design allows for leveling adjustments during installation. Wiring is routed through the base and up the pole interior to the fixture mounting point.

Long-term use requires periodic inspection of the base plate, anchor bolts, and finish. The hot dip galvanized and powder coated finish provides protection against corrosion, but damage to the coating should be repaired promptly. The included top cap should remain in place to prevent water ingress.

How This Fixture Is Commonly Used

This pole is typically installed in rows or perimeters with spacing determined by fixture output, site layout, and required light levels. Common mounting heights are fixed at 10 feet, with fixture selection based on EPA and weight compatibility. Poles are often spaced 2 to 4 times the mounting height, depending on the application and fixture beam spread.

Using higher EPA fixtures or adding multiple fixtures per pole may require closer attention to wind load ratings. Reducing fixture count by increasing output can increase glare or create uneven light distribution at low mounting heights.

Safety, Certifications, and Warranty

This steel pole is engineered to meet structural requirements for area and site lighting applications. EPA ratings are provided for wind speeds up to 120 mph. The pole is finished with hot dip galvanizing and powder coating for corrosion resistance. Includes a 1-year warranty.

All installation and use must comply with local codes and standards for structural and electrical safety. No additional certifications are claimed for this product.

Frequently Asked Questions

Q: What is the maximum fixture EPA this pole can support?

A: The maximum EPA is 26.2 at 70 mph, decreasing to 9.6 at 120 mph. Always check the combined EPA of fixtures and brackets against the wind speed rating for your site.

Q: Can this pole be used for dual fixture mounting?

A: Dual fixture mounting is possible if the combined EPA and weight do not exceed the pole?s rated limits for your wind zone.

Q: What is the recommended foundation for this pole?

A: A concrete foundation with anchor bolts matching the 8-inch bolt circle and 2.75-inch projection is required. Foundation size should be determined by site conditions and local code.

Q: Is this pole suitable for coastal or corrosive environments?

A: The pole is hot dip galvanized and powder coated, but additional protective measures may be needed for coastal or highly corrosive environments.

Q: How should I plan pole spacing for parking lot lighting?

A: Spacing typically ranges from 20 to 40 feet, depending on fixture output, beam spread, and required light levels. Site layout and uniformity requirements should guide final spacing.

Application Questions and Clarification

Q: Can this pole be used for sports facility lighting?

A: Yes, for low-mount sports facility lighting where fixture EPA and weight are within the pole?s ratings. Not suitable for high-mast or large field applications.

Q: Is this pole compatible with all area lighting fixtures?

A: The pole is compatible with fixtures that fit the 3-inch diameter and do not exceed EPA and weight limits. Always verify mounting hardware compatibility.

Q: What maintenance is required for long-term reliability?

A: Inspect the base, anchor bolts, and finish periodically. Repair any coating damage and ensure the top cap remains in place to prevent water ingress.
