45 Watt Detention Grade Surface Mount 1×4 LED Panel | 7000 Lumens | 4000K | 100-277V
This 45 watt detention grade LED panel is a strong choice for secured environments requiring robust, tamper-resistant lighting. Its 16-gauge steel housing, dual-layer lens system, and IK07 impact rating address the durability and security needs of correctional facilities, psychiatric units, and similar spaces where fixtures face physical abuse and unauthorized access attempts. The 7000 lumen output at 4000K ensures clear, neutral illumination for monitoring and safety, while 0-10V dimming supports adaptable light levels. Surface mounting and tamper-resistant fasteners simplify secure installation. This fixture is not intended for wet locations.
Dwayne Kula | President, CTO and Founder
Product Specifications
Key Features
| Brand | LED Lighting Supply |
| Watts | 45 |
| Lumens | 7000 |
| Lumens Per Watt | 156 |
| Replaces | 150 Watt Metal Halide |
| Voltage | 100V-277V |
| Color Temperature | 4000K |
| CRI | 80+ |
| Dimming | 0-10V |
| Optics | .125 Prismatic Acrylic (inner) | .156 Clear Polycarbonate (outer) |
| Lifespan | 100,000 (L70) hours |
| Mounting | Surface |
| Fixture Color | White |
| Frequency (Hz) | 50/60 |
| Power Factor | >0.9 |
Durable Construction
| Housing | 16-Gauge Cold Roll Steel |
| Fasteners | Tamper-Resistant T25 TORX Screws |
| IK Rating | IK07 |
| Certifications | ETL | Rebate Eligible |
| Warranty | 5 years |
Measurements
| Dimensions (in) | 47.75 L x 12.19 W x 4 H |
Product Overview
This 45-watt detention grade surface mount LED panel delivers 7000 lumens at 4000K. It is built for detention facility lighting, correctional facility lighting, secure area lighting, and vandal resistant lighting where exposed fixtures require protected construction.
The 1×4 surface-mounted fixture uses a 16-gauge cold roll steel housing, tamper-resistant T25 TORX screws, and layered prismatic acrylic and clear polycarbonate optics. Its low-profile 4-inch housing suits ceiling-mounted installations where recessed construction is not available.
Core Performance and Output
The fixture produces 7000 lumens from 45 watts, delivering 156 lumens per watt. The 4000K color temperature and 80+ CRI provide neutral white illumination for secure interior spaces.
Inner .125-inch prismatic acrylic and outer .156-inch clear polycarbonate optics protect the light source while distributing light across the fixture face. Output may be excessive in small low-ceiling spaces when fixture placement and light levels are not evaluated.
The fixture operates on 100-277V, 50/60 Hz power and has a power factor greater than 0.9. It is listed as replacing a 150-watt metal halide fixture.
Adjustability and Control Options
This fixture supports 0-10V dimming. Dimming controls must be compatible with the installed 0-10V system.
The 4000K color temperature is fixed. The fixture uses a fixed surface-mount configuration and does not include field-adjustable wattage or color temperature settings.
Longevity and Reliability
The LED system is rated for 100,000 hours L70 life. This rating supports long operating periods where fixture access can be restricted or controlled.
The steel housing, protected optics, and tamper-resistant fasteners address routine physical contact in secure area lighting and tamper resistant lighting installations. Long-term performance still depends on proper mounting, wiring, and control compatibility.
Build Quality and Physical Characteristics
The fixture measures 47.75 inches long, 12.19 inches wide, and 4 inches high. The white 1×4 housing is constructed from 16-gauge cold roll steel.
The optical assembly combines an inner prismatic acrylic lens with an outer clear polycarbonate lens. Tamper-resistant T25 TORX screws secure the fixture enclosure.
The fixture is IK07 rated. Surface mounting keeps the housing accessible for service without requiring a recessed ceiling opening.
Where This Product Fits Best
This fixture fits controlled indoor environments requiring durable surface-mounted lighting and tamper-resistant enclosure hardware. Its form factor is suited to secure rooms, corridors, and detention-related interior areas.
- detention facility lighting
- correctional facility lighting
- secure area lighting
- vandal resistant lighting
- psychiatric facility lighting
- holding cell lighting
- secure corridor lighting
The steel housing, IK07 rating, polycarbonate outer lens, and tamper-resistant fasteners support installations where fixture protection is a primary requirement. Surface mounting requires a suitable ceiling structure and a clear fixture footprint.
Installation and Long-Term Use
The fixture mounts directly to the ceiling surface. Installers need to account for the 47.75-inch fixture length, 12.19-inch width, and 4-inch housing depth before setting fixture locations.
Line voltage, grounding, and 0-10V dimming connections should be verified during installation when controls are used. Tamper-resistant T25 TORX screws require the appropriate tool for access during service.
How This Fixture Is Commonly Used
In detention facility lighting and correctional facility lighting layouts, these panels are surface mounted in repeated ceiling patterns to maintain consistent coverage through secure interior areas. Mounting height and ceiling construction affect placement and final light distribution.
For holding cell lighting and psychiatric facility lighting, fixture locations are typically coordinated with the room layout and required light levels. Higher output can reduce fixture count, but placement must be evaluated to avoid excessive light in smaller spaces.
Secure corridor lighting layouts commonly use aligned fixture rows along the corridor path. Spacing varies with mounting height, target light levels, and the required uniformity across the corridor.
Safety, Certifications, and Warranty
This fixture is ETL listed and rebate eligible. It is IK07 rated.
The fixture includes a 5-year warranty. Tamper-resistant T25 TORX screws, steel construction, and protected optics are integral parts of the fixture assembly.
Frequently Asked Questions
Q: What light output does this detention grade panel provide?
A: The fixture delivers 7000 lumens while operating at 45 watts.
Q: What voltage does this fixture use?
A: The fixture operates on 100-277V, 50/60 Hz power.
Q: Does this fixture support dimming?
A: Yes. The fixture supports 0-10V dimming.
Q: How is this fixture mounted?
A: The fixture is designed for surface mounting.
Q: What hardware secures the fixture enclosure?
A: The enclosure uses tamper-resistant T25 TORX screws.
Q: Is this fixture appropriate for holding cell lighting?
A: Holding cell lighting is a listed application for this detention grade fixture. Final placement should account for the ceiling layout and required light levels.
Application Questions and Clarification
Q: What should be reviewed when planning secure corridor lighting layout?
A: Mounting height, corridor layout, target light levels, and fixture placement should be reviewed. The supplied product data does not establish a specific fixture spacing value.
Q: What fixture characteristics support vandal resistant lighting installations?
A: The fixture has a 16-gauge cold roll steel housing, IK07 rating, tamper-resistant T25 TORX screws, and an outer clear polycarbonate optic.
Q: Can this fixture be used where 100-277V service is present?
A: Yes. The fixture operates on 100-277V power.
