40 Watt Hybrid Solar Area Light | 8000 Lumens | 4000K | 100-277V | High Performance | 5 Year Warranty

Product Overview

The 40 Watt Hybrid Solar Area Light is designed for exterior area illumination where grid power is available but energy savings and off-grid capability are required. This fixture integrates a monocrystalline solar panel with 100-277V AC input, supporting both solar and hybrid operation. Typical use cases include parking lot lighting and street lighting in municipal, campus, and remote site environments where reliability and reduced energy consumption are priorities.

This model delivers 8000 lumens at 4000K with a Type 3 distribution, suitable for pole-mounted applications. The slip fitter mounting and integrated motion sensor support adaptive lighting strategies and straightforward installation on standard poles.

Core Performance and Output

This fixture outputs 8000 lumens at 40 watts, providing 200 lumens per watt efficiency. The Type 3 beam distribution is designed for roadway and area coverage, supporting uniform illumination across parking lots, streets, and pathways. The 4000K color temperature offers neutral white light for visibility and security.

Performance is consistent across the 100-277V input range, with the solar panel supplementing or replacing grid power as available. At mounting heights below 12 feet, output may be excessive for pedestrian-only pathways. Uniformity can decrease at mounting heights above 20 feet without careful layout or supplemental fixtures.

Adjustability and Control Options

The fixture includes an integrated motion sensor for occupancy-based dimming or on/off control. This supports energy savings and targeted illumination in low-traffic periods. The slip fitter mount allows for horizontal and vertical aiming adjustments during installation.

No onboard dimming is provided beyond the motion sensor function. Control integration is limited to the built-in sensor; external control systems are not supported on this model.

Longevity and Reliability

The LED array is rated for 100,000 hours (L70), supporting long-term operation with minimal maintenance. The monocrystalline solar panel and aluminum alloy housing are designed for outdoor exposure and resist corrosion and UV degradation.

Hybrid operation ensures lighting continuity during periods of low solar input or extended overcast conditions. The IP65 rating protects against dust and water ingress, supporting reliable use in exposed environments.

Build Quality and Physical Characteristics

The fixture uses an aluminum alloy housing with a polycarbonate optical lens. The integrated solar panel is monocrystalline for high conversion efficiency. The unit measures 48.2 x 16.6 x 10 inches and weighs 36.4 lbs, supporting pole-top mounting with a slip fitter.

EPA rating is 1.8, suitable for standard area lighting poles in most wind zones. The IP65 enclosure rating ensures protection against rain, dust, and incidental water spray.

Where This Product Fits Best

This hybrid solar area light is suited for outdoor environments where grid power is present but energy savings, backup capability, or off-grid operation are desired. It is commonly installed in municipal, campus, and remote site settings where reliability and reduced maintenance are priorities.

• street lighting
• parking lot lighting
• pathway lighting
• remote site lighting
• municipal lighting
• campus lighting
• off-grid roadway lighting
• park lighting

Environmental characteristics include full outdoor exposure, variable weather, and locations where trenching for power is limited or cost-prohibitive. The fixture is not intended for indoor or covered use.

Installation and Long-Term Use

Slip fitter mounting supports installation on standard round or square poles. The fixture?s weight and EPA rating are compatible with most commercial area lighting poles up to 20 feet, subject to local wind load requirements. Integrated solar panel orientation should be considered for optimal charging.

Routine maintenance is limited to periodic cleaning of the solar panel and lens. Battery replacement intervals depend on site conditions and usage patterns. The hybrid design reduces risk of outages during grid loss or solar deficit.

How This Fixture Is Commonly Used

Typical mounting heights range from 12 to 20 feet for area and street lighting. Spacing is determined by required light levels, pole height, and site geometry, with 2 to 3 fixture pole spacing common for parking lots and roadways.

Fixtures are often deployed in rows along streets or perimeters, or in grid layouts for parking lots. Higher output allows for wider spacing but may increase glare if not aimed or shielded appropriately.

Safety, Certifications, and Warranty

This fixture is IP65 rated. The housing and lens materials are non-corrosive and UV resistant. The product includes a 5-year warranty covering manufacturing defects and LED performance.

No additional safety certifications are specified beyond ingress protection. All components are suitable for outdoor use in commercial and municipal environments.

Frequently Asked Questions

Q: What is the recommended mounting height for this fixture?

A: Mounting heights between 12 and 20 feet are typical for area and street lighting applications.

Q: Does the fixture require grid power to operate?

A: The fixture operates in hybrid mode, using solar power when available and switching to grid power as needed. It does not require grid power at all times.

Q: Is the motion sensor adjustable?

A: The integrated motion sensor is preset for occupancy detection. Sensitivity and time delay settings are not field-adjustable on this model.

Q: What is the expected maintenance interval for the solar panel and battery?

A: The solar panel should be cleaned periodically to maintain charging efficiency. Battery replacement intervals vary by usage but are typically several years under normal conditions.

Q: How should fixtures be spaced for uniform parking lot coverage?

A: Spacing depends on mounting height and required light levels. For 15?20 foot poles, spacing of 2 to 3 pole heights is common for uniform coverage.

Application Questions and Clarification

Q: Can this fixture be used for pathway lighting in parks?

A: Yes, this fixture is suitable for pathway and park lighting when mounted at appropriate heights and spaced for the desired light level.

Q: Is this fixture appropriate for off-grid roadway lighting?

A: The hybrid solar design supports off-grid roadway lighting where grid power is unavailable or unreliable.

Q: Does the fixture support campus or municipal lighting projects?

A: Yes, this model is commonly used in campus and municipal lighting applications requiring energy savings and backup capability.

Q: Are there limitations for use in covered or indoor environments?

A: This fixture is designed for outdoor use only and is not intended for covered or indoor environments.
