10 Watt Solar Post Top Light | 1700 Lumens | 3000K / 4000K / 5000K Adjustable

Product Overview

This 10 Watt Solar Post Top Light is designed for post top and architectural site lighting applications where grid power is unavailable or cost-prohibitive. The fixture integrates a monocrystalline solar panel, battery, and LED array into a single unit, providing autonomous operation. Typical installations include pedestrian pathways, parks, and municipal sites requiring low-maintenance, off-grid illumination. The slip fitter mount supports standard post top poles, and the fixture is suitable for mounting heights up to 12 feet for effective area coverage.

Selectable color temperature (3000K, 4000K, or 5000K) allows adaptation to site requirements or visual preferences. The fixture includes a motion sensor and photocell for adaptive lighting and energy management. IP66 construction supports reliable operation in outdoor environments exposed to rain, dust, and debris.

Core Performance and Output

This fixture delivers 1700 lumens at 10 watts, providing 170 lumens per watt efficiency. Output is comparable to a 100 Watt metal halide post top fixture, supporting pathway and pedestrian area lighting at low to moderate mounting heights. The polycarbonate optic and tempered glass cover provide a uniform, wide distribution suitable for open site layouts and walkways.

Performance is optimized for mounting heights between 8 and 12 feet. Excessive mounting height will reduce ground-level illumination and uniformity. The fixture is not intended for high-output or large-area coverage applications.

Adjustability and Control Options

The fixture offers field-selectable color temperature (3000K, 4000K, 5000K) via onboard controls. Integrated motion sensor enables adaptive dimming or on/off operation based on occupancy, extending battery life and reducing light pollution. The photocell provides dusk-to-dawn automation, ensuring the fixture operates only when needed.

No dimming interface is provided beyond the built-in sensor controls. All adjustments are made at the fixture during installation or maintenance access.

Longevity and Reliability

The LED array is rated for 100,000 hours (L70), supporting long-term operation with minimal maintenance. The monocrystalline solar panel and lithium battery are designed for multi-year service in outdoor environments. IP66 enclosure protects internal components from water ingress, dust, and environmental contaminants.

Routine inspection of the solar panel surface and battery health is recommended to maintain consistent performance over the fixture?s service life.

Build Quality and Physical Characteristics

The fixture housing is constructed from aluminum alloy for corrosion resistance and durability. The integrated solar panel is monocrystalline for high conversion efficiency. The optic is polycarbonate with a tempered glass cover for impact resistance and optical clarity.

Fixture dimensions are 20 x 17 inches, with a total weight of 20 lbs. The slip fitter mount is compatible with standard post top poles. Bronze finish provides a neutral appearance for architectural and municipal settings.

Where This Product Fits Best

This solar post top light is suited for outdoor environments where grid power is unavailable or where autonomous, low-maintenance lighting is required. Typical installations include pedestrian pathways, parks, and municipal or campus sites with moderate foot traffic and low to medium mounting heights.

• street lighting
• pathway lighting
• remote site lighting
• parking lot lighting
• park lighting
• trail lighting
• campus lighting
• municipal lighting

IP66 rating supports use in exposed outdoor locations. The fixture is not intended for high-output roadway or large-area lighting. Performance may be reduced in heavily shaded or obstructed sites where solar charging is limited.

Installation and Long-Term Use

The fixture mounts to standard post top poles using a slip fitter. Installation requires no electrical wiring or trenching, reducing site disruption. All controls and adjustments are accessible at the fixture. The integrated design simplifies deployment in new or retrofit projects.

Long-term use requires periodic cleaning of the solar panel and inspection of battery condition. Battery replacement may be required after several years, depending on site conditions and usage patterns. The fixture is designed for minimal ongoing maintenance in typical outdoor environments.

How This Fixture Is Commonly Used

Commonly installed at mounting heights between 8 and 12 feet, with spacing determined by required light levels and site geometry. Typical layouts provide continuous or staggered coverage along pathways, park trails, or perimeter walkways. Motion sensor operation allows for reduced output or off-state when areas are unoccupied, extending battery life.

Fixture count and spacing should be planned based on target illumination and site-specific factors. Higher output per fixture can reduce total fixture count but may increase localized glare if spacing is too wide or mounting height is low.

Safety, Certifications, and Warranty

This fixture is IP66 rated. The housing and lens materials are impact resistant and suitable for outdoor use. The product includes a 3-year warranty covering manufacturing defects and component failure under normal operating conditions.

No additional safety certifications are specified beyond IP66. All electrical and solar components are fully integrated and require no field wiring.

Frequently Asked Questions

Q: What is the recommended mounting height for this solar post top light?

A: Recommended mounting height is 8 to 12 feet for optimal ground-level illumination and uniformity.

Q: How is the color temperature adjusted?

A: Color temperature is field-selectable at the fixture using onboard controls. Options are 3000K, 4000K, or 5000K.

Q: Does the fixture require electrical wiring?

A: No, the fixture is fully solar powered and does not require connection to grid power or external wiring.

Q: How often does the battery need to be replaced?

A: Battery replacement interval depends on site conditions and usage, but typical service life is several years under normal operation.

Q: Can the motion sensor and photocell be disabled?

A: Both the motion sensor and photocell are integrated and can be configured or disabled at the fixture during installation.

Q: What is the EPA rating of the fixture?

A: The EPA rating is 0.2.

Q: Is this fixture suitable for shaded or obstructed locations?

A: Performance may be reduced in areas with limited sunlight due to shading or obstructions, as solar charging will be affected.

Application Questions and Clarification

Q: Is this fixture appropriate for main roadway or highway lighting?

A: No, output is designed for pathways, parks, and pedestrian areas, not for high-output roadway or highway applications.

Q: Can this fixture be used for campus or municipal pathway lighting?

A: Yes, it is commonly used for campus, municipal, and park pathway lighting where grid power is unavailable or not preferred.

Q: What is the typical spacing between fixtures for pathway applications?

A: Typical spacing is 20 to 30 feet, but actual spacing should be determined by site requirements and target light levels.

Q: Does the fixture support dusk-to-dawn operation?

A: Yes, the integrated photocell enables dusk-to-dawn operation without manual intervention.
