Showing all 4 results
Explosion Proof Rated Junction Box | 3/4 NPT | Class 1 Division 1
SKU:MLLG-E-EXPL-JunctionBox | Web ID:1677- IP Rating: IP67
- Operating Temp: -76°F to +140°F
- Dimensions: 5.6 in X 5.6 in X 4.2 in
- Class 1 Division 1: Group A, B, C, D
- NPT Connections: 3/4 in (Standard) | 1/2 in (built to order)
- Maximum Load: 80 lbs
- Warranty: 5 years
Explosion Proof Rated Junction Box | 3/4 NPT | Class 1 Div 2 | Class 2 Div 2
SKU:MLLG-E-EXPL-JunctionBox-C1D2 | Web ID:1832- IP Rating: IP67
- Operating Temp: -76°F to +140°F
- Dimensions: 5.6 in X 5.6 in X 4.2 in
- Class 1 Division 2: Group A, B, C, D
- NPT Connections: 3/4 in (Standard) | 1/2 in (built to order)
- Maximum Load: 80 lbs
- Warranty: 5 years
Explosion Proof Junction Box | 1/2 in or 3/4 in NPT | Wall or Ceiling Mounted | Built-in Motion Sensor | Class 1 Div 2 | Class 2 Div 2
SKU:MLLG-E-MS-C1D2-JB | Web ID:2055- IP Rating: IP65
- Operating Temp: -22°F to +140°F
- Dimensions: 5.6 in X 5.6 in X 4.2 in
- Class 1 Division 2: Group A, B, C, D
- Voltage: 100V-277V
- Rated Life: 50,000 hours
- Load Capacity 120V: 400 Watts
- Load Capacity 220V-240V: 800 Watts
- Load Capacity 277V: 1000 Watts
- NPT Connections: 3/4 in (Standard) | 1/2 in (built to order)
- Warranty: 5 years
Explosion Proof Junction Box | 1/2 in or 3/4 in NPT | Wall or Ceiling Mounted | Built-in Photocell | Class 1 Div 2 | Class 2 Div 2
SKU:MLLG-E-PC-C1D2-JB | Web ID:2063- IP Rating: IP65
- Operating Temp: -22°F to +140°F
- Dimensions: 5.6 in X 5.6 in X 4.2 in
- Class 1 Division 2: Group A, B, C, D
- Voltage: 100V-277V
- Rated Life: 50,000 hours
- Load Capacity 120V: 400 Watts
- Load Capacity 220V-240V: 800 Watts
- Load Capacity 277V: 1000 Watts
- NPT Connections: 3/4 in (Standard) | 1/2 in (built to order)
- Warranty: 5 years
What Is an Explosion Proof Junction Box?
An explosion proof junction box is a junction box that is UL approved for explosion or hazardous locations. It allows you to mount and connect your explosion proof fixture to the ceiling. In the case of our product, it is both C1D1 andC1D2 rated.
What Makes a Junction Box Explosion Proof?
It’s a junction box designed to pass UL’s strict guidelines for explosion proof ratings, under the main code UL844. Engineers design their product so it can pass these stringent requirements.
When Does It Make Sense to Use Hazardous Area Junction Boxes?
If you are installing any electrical device in a room that requires explosion proof certified products, then an explosion proof j boxes make sense.
How Do You Determine If You Need an Explosion Proof Junction Box for Your Project?
If you are installing any explosion proof rated fixtures in an area, then you will need explosion proof electrical junction boxes and conduit. It is not enough to use just explosion proof rated fixtures and standard conduit and junction boxes. If this is an existing installation, you usually can reuse the junction box and conduit already in place.
How Do You Seal Off Explosion Proof Junction Boxes?
You shouldn’t have to do anything to seal it, other than reassembling it in the exact same way you opened it up to access the connections.
Does the Junction Box Come with an Explosion Proof Conduit?
No, it needs to be ordered separately. If this is an existing installation, you can usually reuse the junction box and conduit already in place.
What Else Do I Need to Install My New Explosion Proof Fixtures If the Installation Is New?
Your local electrical code will be the best guide for this, but you should consider if everything in the room needs to be explosion rated.
