200 / 240 / 300 Watt Adjustable UFO High Bay | 30000 to 45000 Lumens | 3500K / 4000K / 5000K | 120-277V or 277-480V

Product Overview

The 200 / 240 / 300 Watt Adjustable UFO High Bay is designed for high-performance lighting in large indoor spaces. This fixture offers adjustable wattage and color temperature, making it versatile for various lighting needs. It is suitable for replacing traditional 400 to 1000 Watt metal halide fixtures, providing a modern solution with improved energy efficiency and longevity.

With a robust die-cast aluminum housing and an IP65 rating, this fixture is built to withstand challenging environments. It operates efficiently in temperatures ranging from -22°F to 122°F, making it ideal for diverse applications such as warehouses and manufacturing facilities.

Core Performance and Output

This UFO High Bay delivers between 30,000 to 45,000 lumens, depending on the wattage setting, with an efficacy of 150 lumens per watt. It offers three beam angle options: 60°, 90°, and 110°, allowing for tailored light distribution based on the specific needs of the space. The fixture supports both 120-277V and 277-480V inputs, ensuring compatibility with various electrical systems.

While the high output is beneficial for large spaces, it may be excessive for low mounting heights, potentially leading to increased glare. Optimal performance is achieved when installed at appropriate heights to ensure uniform light distribution.

Adjustability and Control Options

This fixture features adjustable wattage and color temperature settings, allowing for customization to meet specific lighting requirements. The 0-10V dimming capability provides further control over light levels, enhancing energy savings and user comfort.

For additional control, a motion sensor with remote control is available, enabling adjustments to detection area, hold time, and standby dimming levels. This feature is particularly useful in spaces where occupancy varies throughout the day.

Longevity and Reliability

With a lifespan of 50,000 hours, this UFO High Bay offers long-term reliability, reducing the need for frequent replacements and maintenance. The fixture's robust construction and high-quality components contribute to its durability, even in demanding environments.

The fixture's surge protection and high power factor ensure stable operation, minimizing the risk of electrical issues and extending the overall lifespan of the lighting system.

Build Quality and Physical Characteristics

The fixture is constructed from die-cast aluminum, providing excellent heat dissipation and structural integrity. Its IP65 and IK08 ratings indicate strong resistance to dust, water, and impact, making it suitable for industrial and commercial settings.

Weighing 3.5 lbs and measuring 14 inches in diameter and 6 inches in height, the fixture is compact yet powerful, allowing for easy installation and integration into existing lighting systems.

Where This Product Fits Best

This UFO High Bay is ideal for environments requiring high-output lighting with adjustable settings. It is particularly suited for large indoor spaces where flexibility and durability are essential.

• warehouse lighting
• manufacturing facility lighting
• distribution center lighting
• gymnasium lighting
• aircraft hangar lighting
• indoor sports facility lighting
• basketball court lighting
• pickleball court lighting

The fixture's robust construction and IP65 rating make it suitable for environments with exposure to dust and moisture, while its adjustable features cater to spaces with varying lighting needs.

Installation and Long-Term Use

Installation options include hook or pendant mounting, providing flexibility based on the structural requirements of the space. The fixture's lightweight design simplifies the installation process, reducing labor time and costs.

For long-term use, regular maintenance checks are recommended to ensure optimal performance. The fixture's durable construction minimizes the need for frequent interventions, contributing to lower operational costs over time.

How This Fixture Is Commonly Used

Commonly installed at heights ranging from 15 to 30 feet, this fixture is suitable for large open areas where high light levels are necessary. The spacing between fixtures can vary based on the desired light levels and specific application requirements.

Higher output settings can reduce the number of fixtures needed, but may increase glare if not properly managed. Adjusting the beam angle and dimming settings can help optimize light distribution and minimize potential issues.

Safety, Certifications, and Warranty

This UFO High Bay is UL and DLC Premium certified, ensuring compliance with industry standards for safety and performance. The fixture includes a 5-year warranty, providing assurance of its quality and reliability.

With an IP65 rating, the fixture is protected against dust and water ingress, while the IK08 rating indicates resistance to mechanical impact. These certifications and ratings confirm the fixture's suitability for demanding environments.

Frequently Asked Questions

Q: What is the recommended mounting height for this fixture?

A: The recommended mounting height ranges from 15 to 30 feet, depending on the specific lighting requirements and application.

Q: Can the color temperature be adjusted after installation?

A: Yes, the color temperature can be adjusted between 3500K, 4000K, and 5000K using the fixture's built-in settings.

Q: Is a motion sensor included with the fixture?

A: A motion sensor is available as an optional accessory and requires a remote control for configuration.

Q: What type of dimming is supported?

A: The fixture supports 0-10V dimming, allowing for smooth adjustments to light levels.

Application Questions and Clarification

Q: Is this fixture suitable for use in a natatorium?

A: Yes, the fixture's IP65 rating makes it suitable for environments with high humidity, such as natatoriums.

Q: Can this fixture be used in agricultural buildings?

A: Yes, it is suitable for agricultural building lighting due to its robust construction and resistance to dust and moisture.

Q: What are the beam angle options available?

A: The fixture offers beam angles of 60°, 90°, and 110°, allowing for tailored light distribution.

Q: How does the fixture perform in cold environments?

A: The fixture operates efficiently in temperatures as low as -22°F, making it suitable for cold environments.
