25 Foot Piling | Class C | .60 CCA Treated | Southern Yellow Pine
Dwayne Kula | President, CTO and Founder
Product Specifications
Key Features
| Brand | LED Lighting Supply |
| Total Height (ft) | 25 |
| ANSI Class | Class C |
| Material | Wood Piling |
| Pole Weight (lbs) | 580-690 |
| Min Pole Top Circ (in) | 19 |
| Min Pole Top OD (in) | 6 |
| Min Circ 3 ft from Butt (in) | 38 |
| OD 3 ft From Butt (in) | 12 |
| Treatment | .60 CCA |
| Opt Treatment | .80 CCA | 1.0 CCA | 1.5 CCA | 2.5 CCA |
| Warranty | 1 year |
Product Description
Key Features
- Brand: LED Lighting Supply
- Total Height (ft): 25
- ANSI Class: Class C
- Material: Wood Piling
- Pole Weight (lbs): 580-690
- Min Pole Top Circ (in): 19
- Min Pole Top OD (in): 6
- Min Circ 3 ft from Butt (in): 38
- OD 3 ft From Butt (in): 12
- Treatment: .60 CCA
- Opt Treatment: .80 CCA | 1.0 CCA | 1.5 CCA | 2.5 CCA
- Warranty: 1 year
Our 25 foot Class C CCA Treated Southern Yellow Pine Pilings are grown, debarked, and treated in the United States. They are manufactured to ASTM D25 standards and are treated to the latest American Wood Preservers Association standards to prevent decay and damage.
USE CASE and CCA TREATMENT LEVELS
- Foundation: 0.6 pounds
- Fresh Water: 0.8 pounds
- Brackish Water, Salt Water: 1.0 pounds
- Salt Water: 1.5 pounds
- Salt Water where marine bores are present (piers, marinas, bulkheads, and jetties): 2.5 pounds
Delivery is made with a flatbed truck and the customer is responsible for offloading. Offloading requires a forklift or appropriate similar machine (customer supplied). Customer is responsible for any costs associated with delivery rescheduling because of improper scheduling or not having the proper offloading equipment available at the time of delivery.
Pricing: Does not include cost of shipping. Shipping is available to the lower 48 USA states. We can supply a budgetary shipping quote or a firm shipping quote that is good for 14 days to your delivery location.
Disclaimer: LED Lighting Supply is not responsible for improper loading (ie what is mounted to the piling), installation costs, or foundation design of piling. Dimensions and specifications of pilings are subject to change without notice but the tip and butt dimensions will always be within ASTM specifications. While our main product line is southern yellow pine, we at times are able to offer other species including douglas fir and red pine. All poles are treated with CCA unless specified otherwise. Our standard treatment is .60 pounds per cubic foot.
Please be advised that our wood pilings are covered solely by a 1-year workmanship warranty, which ensures that the pilings are free from defects from the manufacturing process, and structural integrity, for a period of one year from the date of purchase. This warranty does not cover damage resulting from external factors, misuse, or normal wear and tear.
Web ID: 2619
You may also like...
-
30 Foot Piling | Class A | .60 CCA Treated | Southern Yellow Pine
Minimum Order: 4Minimum Order Total: $3,345.44Built to Order 4 WeeksRetail Price: $836.36 -
30 Foot Piling | Class B | .60 CCA Treated | Southern Yellow Pine
Minimum Order: 4Minimum Order Total: $2,545.44Built to Order 4 WeeksRetail Price: $636.36
Product Overview
The 25 Foot Class C .60 CCA Treated Southern Yellow Pine Piling is designed for use in marine and architectural site lighting applications. This piling is crafted from Southern Yellow Pine, known for its strength and durability, and is treated to resist decay and damage in harsh environments. With a height of 25 feet, it is suitable for various structural applications where stability and longevity are critical.
Manufactured to ASTM D25 standards and treated according to the American Wood Preservers Association guidelines, this piling ensures compliance with industry standards. Its Class C rating and .60 CCA treatment make it a reliable choice for projects requiring robust support in marine settings.
Core Performance and Output
This piling offers a structural capacity that supports a range of marine and architectural applications. With a weight range of 580-690 lbs, it provides substantial support for various structures. The piling's EPA ratings and wind load performance are designed to withstand environmental stresses typical in coastal and waterfront areas.
The 25-foot height allows for versatile use in different construction scenarios, while the wood material offers non-conductivity and corrosion resistance. The piling's performance is optimized for environments where durability and resistance to decay are essential.
Adjustability and Control Options
This piling does not include adjustable features or control options, as it is a fixed structural component. Its primary function is to provide stable support in marine and architectural applications. The treatment options available (.60 CCA, .80 CCA, 1.0 CCA, 1.5 CCA, 2.5 CCA) allow for customization based on specific environmental needs.
Longevity and Reliability
The Southern Yellow Pine material, combined with .60 CCA treatment, ensures long-term reliability and resistance to environmental factors such as moisture and decay. The piling's construction adheres to stringent ASTM D25 and AWPA standards, providing assurance of its durability and performance over time.
With proper installation and maintenance, this piling can offer years of dependable service in demanding marine and architectural environments.
Build Quality and Physical Characteristics
Constructed from high-quality Southern Yellow Pine, this piling features a minimum pole top circumference of 19 inches and a minimum outer diameter of 6 inches. Three feet from the butt, the circumference is 38 inches, with an outer diameter of 12 inches, ensuring robust structural integrity.
The piling's wood material is treated to resist decay, making it suitable for long-term use in challenging environments. Its build quality supports a range of applications where stability and strength are paramount.
Where This Product Fits Best
This piling is ideal for environments requiring durable and reliable structural support, particularly in marine and waterfront settings. Its treatment and build quality make it suitable for use in areas exposed to moisture and environmental stress.
- marine structures
- dock structures
- pier construction
- waterfront structures
- marina construction
- coastal facility construction
- boardwalk structures
- mooring structures
The piling's environmental characteristics include resistance to decay and corrosion, making it a preferred choice for projects in coastal and marine environments.
Installation and Long-Term Use
Installation of this piling requires consideration of ground conditions and environmental factors. Proper installation techniques ensure stability and longevity, particularly in marine and waterfront applications. The piling's weight and dimensions necessitate appropriate equipment and expertise for installation.
Long-term use is supported by the piling's treatment and material quality, which provide resistance to decay and environmental degradation. Regular inspections and maintenance can further extend its service life.
How This Fixture Is Commonly Used
This piling is commonly used in marine and waterfront construction projects, where its height and structural capacity provide essential support. Typical deployment involves spacing based on structural requirements and environmental conditions.
While higher output in terms of structural support can reduce the number of pilings needed, it may also require careful planning to avoid excessive load on individual pilings.
Safety, Certifications, and Warranty
This piling meets ASTM D25 and AWPA standards, ensuring compliance with industry safety and performance requirements. Its Class C rating and .60 CCA treatment provide assurance of its suitability for marine and architectural applications.
A 1-year warranty covers the piling, offering protection against manufacturing defects and ensuring peace of mind for users.
Frequently Asked Questions
Q: What is the weight range of this piling?
A: The weight range of this piling is 580-690 lbs.
Q: What are the treatment options available for this piling?
A: The piling is available with .60 CCA treatment, with optional treatments of .80 CCA, 1.0 CCA, 1.5 CCA, and 2.5 CCA.
Q: What standards does this piling meet?
A: This piling meets ASTM D25 and AWPA standards.
Q: Is this piling suitable for use in coastal environments?
A: Yes, this piling is suitable for coastal environments due to its treatment and material quality, which provide resistance to decay and corrosion.
Application Questions and Clarification
Q: Can this piling be used for pier construction?
A: Yes, this piling is suitable for pier construction due to its structural capacity and resistance to environmental factors.
Q: What is the minimum circumference of the pole top?
A: The minimum circumference of the pole top is 19 inches.
Q: How does the treatment affect the piling's longevity?
A: The treatment enhances the piling's resistance to decay and environmental degradation, contributing to its longevity in marine and waterfront applications.
