20 Foot Above Grade | 25 Foot Total Height Round Fiberglass Light Pole | 6 Inch Diameter | Direct Burial | High Wind Zone Rated
This 20 foot above grade - 25 foot total height fiberglass light pole is a strong choice for outdoor commercial and industrial sites requiring high wind resistance and corrosion durability. Its lightweight 80 pound design simplifies installation, especially in locations where direct burial is preferred over anchor base mounting. The pole's EPA ratings up to 160 mph make it suitable for exposed parking lots, perimeter lighting, and open area site lighting in high wind zones. Fiberglass construction eliminates rust concerns and minimizes maintenance, while the acrylic enamel finish maintains appearance. The 15 year warranty further supports long-term reliability in demanding environments.
Dwayne Kula | President, CTO and Founder
Product Description
Key Features
- Total Height (ft): 25
- Height Above Grade (ft): 20
- Buried Depth Below Grade (ft): 5
- Material: Fiberglass
- Pole Weight (lbs): 80
- Pole Diameter (in): 6
- Pole Finish: Acrylic Enamel
- Pole Color: Bronze | Custom
- Pole Installation: Direct Burial
- Warranty: 15 years
- EPA at 70 mph: 12
- EPA at 100 mph: 7.5
- EPA at 130 mph: 5.5
- EPA at 160 mph: 3
Disclaimer: LED Lighting Supply is not responsible for improper loading of light fixtures or other attachments, improper use, or foundation design of light poles. We act solely as a supplier of lighting solutions, including metal halide replacement fixtures and parking lot light poles. Final pole assembly and installation are the responsibility of the purchaser.
Dimensions and specifications for round or square composite light poles are subject to change without notice. Please refer to the current data sheet for the most up-to-date specifications. Custom sizing is available only for large-quantity orders. Pole caps may be used in place of other mounting options when required.
Composite light poles are covered by a 15-year workmanship warranty, which warrants that the poles are free from manufacturing defects - including weld and structural integrity issues - at the time of shipment. Any pole found to be defective, upon examination, during normal use and service within 15 years from the date of shipment will be repaired or replaced at our discretion. This warranty does not cover damage resulting from external factors, misuse, or normal wear and tear.
Web ID: 2344
Product Overview
This 20-foot above-grade fiberglass light pole is designed for applications requiring durability and high wind resistance. With a total height of 25 feet and a 6-inch diameter, it is suitable for direct burial installation, making it a reliable choice for environments where structural integrity is paramount. The pole's acrylic enamel finish provides additional protection against environmental factors, ensuring longevity in various settings.
Fiberglass construction offers a lightweight yet robust solution, weighing only 80 pounds, which simplifies handling and installation. This pole is particularly suited for high wind zones, with EPA ratings that support its use in areas experiencing wind speeds up to 160 mph. Its design and material make it an ideal choice for coastal and corrosive environments.
Core Performance and Output
The structural capacity of this fiberglass light pole is defined by its EPA ratings, which are 12 at 70 mph, 7.5 at 100 mph, 5.5 at 130 mph, and 3 at 160 mph. These ratings ensure the pole can support various lighting fixtures while maintaining stability in high wind conditions. The direct burial installation method provides a secure foundation, reducing the risk of pole movement or failure.
Fiberglass material offers excellent corrosion resistance, making it suitable for coastal and corrosive environments. The pole's non-conductive nature enhances safety, particularly in areas prone to electrical storms. Its flexibility under load allows it to withstand environmental stresses without compromising structural integrity.
Adjustability and Control Options
This fiberglass light pole does not include integrated adjustability or control options. However, its design allows for compatibility with a wide range of lighting fixtures and control systems. The pole's height and diameter accommodate various mounting brackets and accessories, enabling customization based on specific lighting requirements.
While the pole itself does not offer direct control features, it can be paired with lighting fixtures that include dimming or smart control capabilities. This flexibility allows for tailored lighting solutions that meet the needs of different applications and environments.
Longevity and Reliability
Constructed from fiberglass, this light pole offers a long service life, supported by a 15-year warranty. The material's inherent resistance to corrosion and environmental degradation ensures reliable performance over time, even in harsh conditions. The acrylic enamel finish adds an extra layer of protection, enhancing the pole's durability.
The pole's design and material selection contribute to its reliability, making it a dependable choice for installations in high wind zones and corrosive environments. Its lightweight nature simplifies installation and reduces the risk of damage during handling and setup.
Build Quality and Physical Characteristics
This light pole features a robust fiberglass construction with a 6-inch diameter and a total height of 25 feet, with 20 feet above grade. The pole's weight of 80 pounds facilitates easy handling and installation. The acrylic enamel finish provides a smooth, durable surface that resists environmental wear and tear.
Available in a standard bronze color, with custom color options, the pole can be tailored to match specific aesthetic requirements. The direct burial installation method ensures a secure and stable foundation, critical for maintaining structural integrity in high wind conditions.
Where This Product Fits Best
This fiberglass light pole is best suited for environments requiring high wind resistance and corrosion protection. Its design and material make it ideal for coastal and corrosive settings, as well as areas prone to high winds.
- baseball field lighting
- softball field lighting
- soccer field lighting
- football field lighting
- sports field lighting
- driving range lighting
- coastal lighting
- corrosive environment lighting
The pole's fiberglass construction provides excellent resistance to environmental factors, making it suitable for installations in coastal areas and other corrosive environments. Its high wind zone rating ensures stability and reliability in challenging conditions.
Installation and Long-Term Use
Installation of this fiberglass light pole involves direct burial, requiring a 5-foot depth below grade for secure placement. The lightweight nature of the pole simplifies handling and setup, reducing installation time and labor costs. Its non-conductive material enhances safety during installation and operation.
Long-term use is supported by the pole's corrosion-resistant fiberglass construction and durable acrylic enamel finish. These features ensure the pole maintains its structural integrity and appearance over time, even in harsh environmental conditions.
How This Fixture Is Commonly Used
This light pole is commonly used in outdoor sports fields and coastal environments where high wind resistance and corrosion protection are essential. Typical mounting heights are 20 feet above grade, providing adequate elevation for effective lighting distribution.
Spacing and layout patterns depend on the specific lighting requirements and fixture types used. The pole's high wind zone rating allows for reduced fixture count in areas with high wind speeds, balancing performance and cost-effectiveness.
Safety, Certifications, and Warranty
This fiberglass light pole is rated for high wind zones, with EPA ratings supporting its use in areas with wind speeds up to 160 mph. Its non-conductive material enhances safety, particularly in environments prone to electrical storms.
The pole comes with a 15-year warranty, reflecting its durability and reliability in various environmental conditions. Its corrosion-resistant construction ensures long-term performance, making it a dependable choice for challenging installations.
Frequently Asked Questions
Q: What is the total height of the pole
A: The total height of the pole is 25 feet, with 20 feet above grade.
Q: What is the pole's EPA rating for high wind zones
A: The pole's EPA ratings are 12 at 70 mph, 7.5 at 100 mph, 5.5 at 130 mph, and 3 at 160 mph.
Q: What material is the pole made from
A: The pole is made from fiberglass, offering excellent corrosion resistance and durability.
Q: How is the pole installed
A: The pole is installed using a direct burial method, requiring a 5-foot depth below grade.
Q: What is the warranty period for this pole
A: The pole comes with a 15-year warranty.
Application Questions and Clarification
Q: Is this pole suitable for coastal environments
A: Yes, the fiberglass construction provides excellent corrosion resistance, making it suitable for coastal environments.
Q: Can this pole be used for sports field lighting
A: Yes, it is suitable for sports field lighting, including baseball, softball, soccer, and football fields.
Q: What are the typical applications for this pole
A: Typical applications include sports field lighting, coastal lighting, and corrosive environment lighting.
Q: How does the pole perform in high wind zones
A: The pole is rated for high wind zones, with EPA ratings supporting its use in areas with wind speeds up to 160 mph.
