4 Fixture 180 Degree Bullhorn Mount | 2 3/8 Inch Tenon | Bronze | Low Profile

Product Overview

This is a 4 Fixture 180 Degree Bullhorn Mount designed for mounting four light fixtures in a low-profile, 180-degree configuration. It installs onto a standard 2 3/8 inch tenon, commonly found on steel or aluminum light poles. The bronze finish provides a neutral appearance suitable for architectural and site lighting environments. This mount is typically used where multiple fixtures need to be oriented in a wide spread from a single pole location, such as parking lots or commercial site perimeters.

The bullhorn is engineered for outdoor use and supports up to four fixtures, allowing for flexible aiming and coverage. Its low-profile design minimizes wind load while maintaining fixture stability. This mounting accessory is often specified for new installations or retrofit projects where multi-directional lighting is required from a single pole.

Core Performance and Output

The bullhorn mount supports four fixtures arranged in a 180-degree spread, enabling broad area coverage from a single pole. The EPA (Effective Projected Area) rating is 2.2, which is critical for calculating total wind load when combined with fixtures. The mount is rated to handle the combined weight and wind load of typical area or site lighting fixtures within its EPA and weight limits.

Structural performance is optimized for use with standard 2 3/8 inch tenons. The 41 lb weight provides stability without excessive load on the pole. When specifying fixtures, ensure the total EPA and weight do not exceed the pole?s rated capacity. Excessive fixture size or mounting height may require additional structural review.

Adjustability and Control Options

This bullhorn mount provides fixed 180-degree fixture spacing, allowing each fixture to be aimed outward for wide coverage. Each arm is designed to accept standard slipfitter or yoke-mount fixtures compatible with 2 3/8 inch tenons. There are no integrated tilt or rotation adjustments beyond the fixture?s own mounting hardware.

No electrical or control features are included with the mount. All fixture-level controls, such as photocells or motion sensors, must be specified at the fixture level. The mount does not restrict the use of dimming or control systems integrated into the fixtures themselves.

Longevity and Reliability

The mount is constructed from durable materials suitable for outdoor environments. The bronze finish provides corrosion resistance for typical site lighting conditions. The design minimizes exposed hardware and reduces the risk of wind-induced vibration or fixture movement.

Routine inspection of mounting hardware and fixture attachment points is recommended as part of standard maintenance. The 1-year warranty covers material and manufacturing defects. Environmental exposure, such as coastal or highly corrosive locations, may require additional protective measures.

Build Quality and Physical Characteristics

This bullhorn mount is fabricated for strength and stability, supporting up to four fixtures in a balanced 180-degree configuration. The 2 3/8 inch tenon interface is compatible with most commercial and industrial light poles. The bronze powder-coated finish is standard for architectural site applications.

The mount weighs 41 lbs, which should be considered when calculating total pole load. All welds and attachment points are designed for outdoor durability. The low-profile design reduces wind resistance and visual bulk compared to larger multi-fixture mounts.

Where This Product Fits Best

This bullhorn mount is intended for exterior site lighting where multiple fixtures are required on a single pole. It is most often used in environments that demand wide area coverage and flexible fixture orientation.

• parking lot lighting
• area lighting
• commercial site lighting
• roadway lighting
• sports facility lighting
• campus lighting
• industrial yard lighting
• dealership lighting

Suitable for outdoor use in standard commercial, municipal, and institutional environments. Not intended for marine, corrosive, or hazardous locations without additional protection.

Installation and Long-Term Use

The mount installs onto a 2 3/8 inch tenon using standard set screws or bolts. Ensure the pole and foundation are rated for the combined weight and EPA of the mount plus all fixtures. Typical installation requires two personnel for safe handling and alignment.

Long-term use depends on regular inspection of mounting hardware and fixture attachment points. The bronze finish resists corrosion in most environments, but additional maintenance may be needed in coastal or high-salt areas. Periodic tightening of set screws is recommended to prevent fixture movement over time.

How This Fixture Is Commonly Used

This bullhorn mount is typically installed at mounting heights ranging from 15 to 30 feet, depending on fixture type and site requirements. Fixtures are spaced evenly along the 180-degree arc to maximize area coverage and minimize shadowing.

Spacing between poles is determined by fixture output and site lighting criteria. Using higher output fixtures can reduce the number of poles required but may increase glare if not properly aimed. Always verify that the total EPA and weight do not exceed the pole?s structural limits.

Safety, Certifications, and Warranty

The mount is designed for outdoor use and meets standard structural and material requirements for site lighting accessories. EPA rating is 2.2. Weight is 41 lbs. No additional electrical or safety certifications apply to this mounting accessory.

Warranty is 1 year, covering material and manufacturing defects. Follow all local codes and best practices for pole and fixture installation to ensure safe operation.

Frequently Asked Questions

Q: What is the maximum EPA and weight this bullhorn mount can support?

A: The mount itself has an EPA of 2.2 and weighs 41 lbs. Total supported EPA and weight depend on the pole?s rating and the combined fixtures installed.

Q: What tenon size is required for installation?

A: This mount is designed for a 2 3/8 inch tenon, which is standard for most commercial light poles.

Q: Can this mount be used in coastal or corrosive environments?

A: The bronze finish provides basic corrosion resistance, but additional protection may be needed for coastal or highly corrosive locations.

Q: Are there any adjustments for fixture aiming on the mount itself?

A: The mount provides fixed 180-degree spacing. Aiming adjustments must be made at the fixture level using compatible mounting hardware.

Q: How should I plan pole spacing and fixture layout with this mount?

A: Pole spacing and fixture layout depend on fixture output, mounting height, and site lighting requirements. Confirm total EPA and weight do not exceed pole capacity.

Application Questions and Clarification

Q: Is this bullhorn mount compatible with all types of area and site lighting fixtures?

A: It is compatible with fixtures that accept a 2 3/8 inch tenon and are within the mount?s EPA and weight limits.

Q: Can this mount be used for sports facility lighting applications?

A: Yes, it is commonly used for sports facility lighting when multiple fixtures are needed on a single pole.

Q: What maintenance is required for long-term reliability?

A: Periodic inspection and tightening of mounting hardware are recommended. Inspect for corrosion or movement during routine maintenance.
