3 Fixture 180 Degree Bullhorn Mount | 2 3/8 Inch Tenon | Bronze | Low Profile

Product Overview

This 3 Fixture 180 Degree Bullhorn Mount is designed for mounting three lighting fixtures in a wide, evenly spaced configuration on a single pole. The mount attaches to a standard 2 3/8 inch tenon and provides a 180-degree spread, supporting fixtures for broad area coverage. The bronze finish offers a neutral appearance suitable for sports field and stadium environments. Typical use includes mounting flood lights or area lights on poles for sports field lighting, stadium lighting, or large outdoor venues where wide distribution is required.

The low-profile design minimizes wind load while maintaining structural integrity. This mount is commonly specified for new pole installations or retrofit projects where multiple fixtures must be aimed in different directions from a single mounting point.

Core Performance and Output

This bullhorn mount supports three fixtures, each positioned at 180 degrees for maximum lateral coverage. The EPA (Effective Projected Area) rating is 1.6, which is critical for calculating total wind load on the pole and ensuring structural safety. The mount weighs 28 lbs, which must be factored into total pole loading calculations along with the fixtures themselves.

The 2 3/8 inch tenon interface is compatible with most commercial and sports lighting fixtures designed for tenon mounting. Excessive fixture weight or high EPA fixtures may exceed pole or mount capacity, especially in high wind zones. Always verify total EPA and weight against pole specifications before installation.

Adjustability and Control Options

This bullhorn mount provides fixed 180-degree spacing between fixtures. Each fixture arm is designed for secure attachment and stable aiming. The mount does not include integrated tilt or rotation adjustments; fixture aiming is determined by the fixture?s own mounting hardware.

No electrical control or integrated wiring is included. All fixture wiring and control integration must be managed at the fixture or pole level. This mount is intended for static, permanent installations where fixture orientation remains consistent.

Longevity and Reliability

The mount is constructed from durable materials with a bronze finish for corrosion resistance in outdoor environments. The design is intended for long-term use in exposed locations, including sports fields and stadiums.

Mechanical reliability is dependent on proper installation and adherence to EPA and weight limits. The 1-year warranty covers material and manufacturing defects. Regular inspection is recommended in high-wind or corrosive environments.

Build Quality and Physical Characteristics

This bullhorn mount features a low-profile, welded construction for strength and stability. The bronze powder-coated finish provides resistance to weathering and UV exposure. The mount weighs 28 lbs and is engineered to minimize additional wind load on the pole.

The 2 3/8 inch tenon interface is industry standard for pole-top mounting. All welds and attachment points are designed for secure, vibration-resistant installation. The mount is suitable for use with most commercial flood and area lighting fixtures compatible with tenon arms.

Where This Product Fits Best

This bullhorn mount is intended for outdoor environments where multiple fixtures must be installed on a single pole for wide area coverage. It is most commonly used in sports field and stadium lighting projects, as well as other large-scale exterior lighting applications requiring broad, even distribution from a single mounting point.

• sports field lighting
• stadium lighting
• baseball field lighting
• softball field lighting
• soccer field lighting
• football field lighting
• recreational field lighting
• driving range lighting

The mount is suitable for outdoor use in both new construction and retrofit projects. It is designed to withstand typical environmental exposure, but total wind load and fixture weight must be considered for each installation.

Installation and Long-Term Use

The mount installs directly onto a 2 3/8 inch pole tenon using standard hardware. All three fixture arms are fixed at 180 degrees, allowing for wide lateral coverage. Installation requires secure attachment to the pole and proper alignment of fixtures for optimal light distribution.

Long-term reliability depends on adherence to EPA and weight limits, as well as periodic inspection for corrosion or mechanical wear. The mount is intended for permanent installations and is not designed for frequent reconfiguration or relocation.

How This Fixture Is Commonly Used

This bullhorn mount is typically installed at mounting heights ranging from 20 to 40 feet, depending on the pole and fixture type. Spacing between poles is determined by the lighting layout and required coverage for the field or venue.

Fixtures are mounted to each arm and aimed using the fixture?s own adjustment hardware. Using higher output fixtures can reduce the number of poles required but may increase glare or require careful aiming to avoid light spill. Layouts often use multiple bullhorn mounts to achieve uniform coverage across large fields.

Safety, Certifications, and Warranty

This mount is designed for structural safety in outdoor environments. The EPA rating of 1.6 and weight of 28 lbs must be included in all pole loading calculations. The product is covered by a 1-year warranty.

No electrical or lighting certifications apply to this mounting accessory. All safety and compliance requirements must be met at the fixture and pole level. Follow all local codes and engineering guidelines for pole and fixture installation.

Frequently Asked Questions

Q: What is the maximum EPA and weight this mount adds to a pole?

A: The mount has an EPA of 1.6 and weighs 28 lbs. Add these values to the total pole load calculation along with the fixtures.

Q: What tenon size is required for installation?

A: The mount is designed for a 2 3/8 inch tenon, which is standard for most commercial and sports lighting poles.

Q: Can the fixture arms be adjusted or rotated after installation?

A: The arms are fixed at 180 degrees. Fixture aiming is managed by the fixture?s own mounting hardware, not the bullhorn mount itself.

Q: Is this mount suitable for use in coastal or corrosive environments?

A: The bronze finish provides basic corrosion resistance. For highly corrosive environments, additional protective measures may be required.

Q: How should I plan pole spacing and fixture layout when using this mount?

A: Pole spacing and fixture layout depend on the field size, fixture output, and aiming requirements. Consult a lighting layout or photometric plan for optimal results.

Application Questions and Clarification

Q: Can this mount be used for general area lighting or parking lot lighting?

A: This mount is designed for sports field and stadium lighting applications. It is not intended for general area or parking lot lighting layouts.

Q: What types of fixtures are compatible with this bullhorn mount?

A: Any fixture with a tenon slipfitter designed for 2 3/8 inch arms can be used, provided total EPA and weight limits are not exceeded.

Q: Is this mount compatible with wood, steel, or fiberglass poles?

A: The mount can be installed on any pole with a 2 3/8 inch tenon, regardless of pole material, as long as the pole meets structural requirements.
