38 Foot Above Grade Round Fiberglass Pole | 11.85 Inch Diameter | Direct Burial | 45 Foot Class 2 Wood Pole Equivalent | High Wind Zone Rated
This 38 foot above grade fiberglass pole is a strong choice for outdoor lighting in demanding environments due to its non-conductive, fire and corrosion resistant construction, direct burial installation, and high wind zone EPA ratings up to 160 mph. The fluoropolymer coating and UV protective paint support long-term durability and appearance, while the pole's flexibility under wind load reduces the risk of failure. Its ANSI Class 2 rating and 7 year warranty add confidence for buyers. Ideal applications include coastal areas, industrial sites, and sports complexes where severe weather, corrosion, or electrical safety are concerns.
Neil Peterson | CEO and Chief Lighting Specialist
Product Specifications
Key Features
| Brand | LED Lighting Supply |
| Total Height (ft) | 45 |
| Height Above Grade (ft) | 38 |
| Buried Depth Below Grade (ft) | 7 |
| ANSI Class | Class 2 |
| Material | Fiberglass |
| Pole Weight (lbs) | 760 |
| Pole Diameter (in) | 11.85 |
| Pole Finish | Fluoropolymer Coating |
| Pole Color | Bronze | Black | White | Gray | Custom |
| Pole Gauge | .532 in |
| Pole Installation | Direct Burial |
| Includes | Top Cap |
| Warranty | 7 years |
| EPA at 70 mph | 142 |
| EPA at 80 mph | 104 |
| EPA at 90 mph | 78 |
| EPA at 100 mph | 59.4 |
| EPA at 110 mph | 45.5 |
| EPA at 120 mph | 35 |
| EPA at 130 mph | 26 |
| EPA at 140 mph | 20 |
| EPA at 150 mph | 15 |
| EPA at 160 mph | 10.5 |
Product Description
Key Features
- Brand: LED Lighting Supply
- Total Height (ft): 45
- Height Above Grade (ft): 38
- Buried Depth Below Grade (ft): 7
- ANSI Class: Class 2
- Material: Fiberglass
- Pole Weight (lbs): 760
- Pole Diameter (in): 11.85
- Pole Finish: Fluoropolymer Coating
- Pole Color: Bronze | Black | White | Gray | Custom
- Pole Gauge: .532 in
- Pole Installation: Direct Burial
- Includes: Top Cap
- Warranty: 7 years
- EPA at 70 mph: 142
- EPA at 80 mph: 104
- EPA at 90 mph: 78
- EPA at 100 mph: 59.4
- EPA at 110 mph: 45.5
- EPA at 120 mph: 35
- EPA at 130 mph: 26
- EPA at 140 mph: 20
- EPA at 150 mph: 15
- EPA at 160 mph: 10.5
Benefits:
- Lightweight, easier to unload and install, saving on labor costs
- Does not rot, rust, or corrode.
- Non-conductive
- Does not break down with age, coated in 25-year UV protective paint
- Stronger than equivalent steel in compression and tension, providing excellent durability and longevity in high wind conditions
- Designed to bend, not break, meaning that poles can naturally bend due to weather conditions and will return to their original form
- Fire resistance: poles do not sustain a flame as there is no fuel source for fire
- Color selection: Bronze, Black, White, or Grey
Disclaimer: LED Lighting Supply is not responsible for improper loading of light fixtures or other attachments, use, or foundation design of light poles. We are solely a supplier of lighting solutions, metal halide replacement lights and poles for parking lots. Final pole assembly is the responsibility of the purchaser. Dimensions and specifications of a round or square composite light pole are subject to change without notice. See the data sheet for current pole data charts. Custom sizing is only available for large order quantities. Pole caps are used in place of other mounting options when necessary.
Please be advised that our composite poles are covered solely by a 7-year workmanship warranty, which ensures that the poles are free from defects from the manufacturing process. This warranty does not cover damage resulting from external factors, misuse, or normal wear and tear.
Web ID: 2210
You may also like...
-
45 Foot Wood Pole | Class 2 | Treated | Southern Yellow Pine
Minimum Order: 4Minimum Order Total: $4,800.00Built to Order 5 WeeksRetail Price: $1,200.00 -
6 Foot Fiberglass Crossarm | 5 in x 5 in x 6 ft | Hardware Included | Fits 5 to 9 in Diameter Poles
Minimum Order: 2Minimum Order Total: $1,393.34Availability: 12 In Stock Ships 2-3 weeksRetail Price: $696.67 -
8 Foot Fiberglass Crossarm | 5 in x 5 in x 8 ft | Hardware Included | Fits 5 to 9 in Diameter Poles
Minimum Order: 4Minimum Order Total: $3,190.68Availability: 12 In Stock Ships 2-3 weeksRetail Price: $797.67
Product Overview
The 38 Foot Above Grade Round Fiberglass Pole is engineered for robust performance in high wind zones, making it suitable for sports field and stadium lighting. With a total height of 45 feet and a direct burial installation, this pole is equivalent to a Class 2 wood pole. Its fiberglass construction ensures non-conductivity and fire resistance, providing a reliable solution for environments where safety and durability are paramount.
This pole features a fluoropolymer coating that enhances its longevity by protecting against UV degradation. Available in multiple colors, it offers flexibility in aesthetic integration with existing infrastructure. The pole's design allows it to bend rather than break under stress, ensuring resilience in adverse weather conditions.
Core Performance and Output
The fiberglass pole is designed to withstand high wind conditions with EPA ratings up to 160 mph. Its structural capacity supports various lighting fixtures, ensuring stability and safety. The pole's non-conductive material enhances safety, particularly in environments prone to electrical hazards.
With a buried depth of 7 feet, the pole provides a stable foundation, reducing the risk of tipping or structural failure. The fluoropolymer coating ensures resistance to corrosion and environmental wear, making it suitable for long-term outdoor use.
Adjustability and Control Options
This fiberglass pole does not include adjustable features or control options. Its primary function is to provide a stable and durable mounting solution for lighting fixtures in high wind areas. The pole's design focuses on structural integrity and environmental resilience rather than adjustability.
Longevity and Reliability
Constructed from fiberglass, this pole offers superior longevity compared to traditional materials like wood or steel. It does not rot, rust, or corrode, ensuring a long service life with minimal maintenance. The UV protective paint further extends its lifespan by preventing degradation from sun exposure.
The pole's ability to bend under stress without breaking enhances its reliability in high wind zones. This characteristic reduces the likelihood of catastrophic failure, providing peace of mind in challenging environments.
Build Quality and Physical Characteristics
The pole's build quality is characterized by its lightweight yet strong fiberglass construction. Weighing 760 lbs, it is easier to handle and install compared to heavier materials. The 11.85-inch diameter and .532-inch gauge provide a robust structure capable of supporting various lighting fixtures.
Available in colors such as Bronze, Black, White, and Gray, the pole can be customized to match the aesthetic requirements of different installations. The fluoropolymer coating ensures a smooth finish that resists environmental wear.
Where This Product Fits Best
This fiberglass pole is ideal for environments requiring durable and non-conductive lighting solutions, particularly in high wind zones.
- baseball field lighting
- softball field lighting
- soccer field lighting
- football field lighting
- sports field lighting
- driving range lighting
- coastal lighting
- corrosive environment lighting
The pole's non-conductive and fire-resistant properties make it suitable for areas with electrical safety concerns. Its ability to withstand high winds ensures reliability in exposed locations.
Installation and Long-Term Use
Installation involves direct burial, requiring a 7-foot depth below grade for stability. The lightweight nature of fiberglass simplifies handling and reduces labor costs during installation. Once installed, the pole requires minimal maintenance due to its resistance to rot, rust, and corrosion.
Long-term use is supported by the pole's UV protective coating, which prevents degradation from sun exposure. The pole's design allows it to bend under stress, reducing the risk of breakage in high wind conditions.
How This Fixture Is Commonly Used
Commonly installed in sports fields and stadiums, this pole supports lighting fixtures at heights up to 38 feet above grade. Typical spacing and layout depend on the specific lighting requirements and fixture types used. The pole's high wind rating makes it suitable for open and exposed areas.
While higher mounting heights can reduce the number of poles needed, they may also require careful consideration of fixture weight and wind load to maintain stability.
Safety, Certifications, and Warranty
This fiberglass pole is ANSI Class 2 rated, ensuring compliance with industry standards for safety and performance. Its non-conductive and fire-resistant properties enhance safety in environments with electrical hazards.
The pole comes with a 7-year warranty, providing assurance of its durability and performance over time. The fluoropolymer coating and UV protective paint contribute to its long-term reliability.
Frequently Asked Questions
Q: What is the maximum wind speed this pole can withstand?
A: The pole is rated for wind speeds up to 160 mph.
Q: What is the buried depth required for installation?
A: The pole requires a buried depth of 7 feet for proper installation.
Q: Is the pole available in different colors?
A: Yes, the pole is available in Bronze, Black, White, and Gray, with custom colors also available.
Q: Does the pole require any maintenance?
A: The pole requires minimal maintenance due to its resistance to rot, rust, and corrosion.
Q: Can this pole be used in corrosive environments?
A: Yes, the pole's fluoropolymer coating and fiberglass construction make it suitable for corrosive environments.
Application Questions and Clarification
Q: Is this pole suitable for coastal lighting applications?
A: Yes, the pole's non-corrosive properties make it ideal for coastal lighting applications.
Q: Can this pole be used for sports field lighting?
A: Yes, it is commonly used for baseball, softball, soccer, and football field lighting.
Q: What is the equivalent wood pole class for this fiberglass pole?
A: This fiberglass pole is equivalent to a Class 2 wood pole.
Q: How does the pole's design contribute to its durability?
A: The pole is designed to bend rather than break under stress, enhancing its durability in high wind conditions.
