30 Foot Square Steel Light Pole | 5 Inches Wide | Anchor Base

Product Overview

This 30 foot square steel light pole is designed for mounting area and site lighting fixtures in commercial and industrial environments. The pole features a 5 inch wide square profile, 11 gauge steel construction, and an anchor base for secure installation on concrete foundations. A 2 3/8 inch tenon is included for direct mounting of standard slipfitter fixtures. Typical use cases include parking lot lighting, roadway lighting, and sports facility lighting where elevated mounting heights are required for broad, uniform coverage.

The pole is hot dip galvanized and powder coated for corrosion resistance and durability in outdoor settings. Multiple color options are available to match site requirements. This pole is commonly specified for new construction and retrofit projects where structural integrity and long-term performance are critical.

Core Performance and Output

The 30 foot height supports mounting of multiple luminaires for wide area coverage and increased uniformity. The pole is rated for a maximum Effective Projected Area (EPA) of 9.6 at 70 mph, with decreasing EPA ratings at higher wind speeds. This allows for mounting of several standard LED area lights or flood lights, depending on fixture size and wind exposure.

Structural performance is maintained through 11 gauge steel and a robust anchor base. The 5 inch width provides stability for tall installations. Excessive fixture loading or mounting in high wind zones above the listed EPA limits can compromise pole integrity and is not recommended. For installations in coastal or extreme wind environments, verify EPA and foundation requirements before deployment.

Adjustability and Control Options

This pole includes a 2 3/8 inch tenon for slipfitter-mounted fixtures, supporting a range of aiming and orientation adjustments at the fixture level. The square profile allows for precise alignment of fixtures in multiple directions. Additional mounting hardware or brackets can be used for multi-fixture arrays or custom configurations.

No integrated electrical controls or access doors are provided on the pole itself. All wiring and control components must be routed through the pole and managed at the fixture or base level. Ensure compatibility with fixture mounting hardware and control systems during planning.

Longevity and Reliability

The pole is constructed from 11 gauge steel and finished with hot dip galvanizing plus powder coating for long-term corrosion resistance. This dual-layer protection is suitable for standard outdoor environments, including parking lots and commercial sites exposed to weather.

Routine inspection of the finish and anchor hardware is recommended to maintain structural reliability. In areas with high salt exposure or aggressive environmental conditions, periodic maintenance may be required to prevent corrosion at base plates and mounting points.

Build Quality and Physical Characteristics

The pole measures 30 feet in total height, with a 5 inch square cross-section and a total weight of 286 lbs. The anchor base design uses a 9.85 inch by 9.85 inch base plate, 0.79 inches thick, with an 8 inch bolt circle and 3.375 inch bolt projection. The included tenon is 2 3/8 inches in diameter for standard slipfitter compatibility.

Available in bronze, black, or white powder coat finishes. The pole is designed for upright installation on concrete foundations using anchor bolts (not included). All welds and structural components meet commercial-grade standards for outdoor lighting support.

Where This Product Fits Best

This pole is suited for outdoor environments requiring elevated mounting of area and site lighting fixtures. Common installations include commercial parking lots, roadways, and large site perimeters where 30 foot mounting heights are needed for optimal light distribution and reduced fixture count.

• parking lot lighting
• roadway lighting
• area lighting
• commercial site lighting
• sports facility lighting
• campus lighting
• industrial yard lighting
• dealership lighting

The hot dip galvanized and powder coated finish provides resistance to weather and corrosion. The pole is suitable for most standard outdoor commercial and industrial sites. For coastal or high-wind regions, confirm EPA and foundation requirements before installation.

Installation and Long-Term Use

Installation requires a concrete foundation with anchor bolts set to match the 8 inch bolt circle and 3.375 inch projection. The pole is delivered with a 2 3/8 inch tenon for direct fixture mounting. All wiring should be routed through the pole interior and terminated at the fixture or base as required by code.

Routine inspection of anchor hardware, base plate, and finish is recommended to ensure long-term structural integrity. For multi-fixture arrays or high wind areas, verify that total EPA and weight do not exceed rated limits. Periodic cleaning and touch-up of the finish may be needed in harsh environments.

How This Fixture Is Commonly Used

Typical mounting height is 30 feet, supporting wide area coverage with fewer poles compared to lower mounting heights. Fixture spacing and layout depend on site geometry, light level requirements, and fixture output. Poles are often spaced 80 - 120 feet apart in parking lots or along roadways, but actual spacing should be determined by photometric analysis.

Multiple fixtures can be mounted per pole, provided total EPA and weight remain within rated limits. Higher mounting heights reduce glare and improve uniformity but may require higher output fixtures. For sports facility or dealership applications, custom mounting brackets may be used for multi-directional lighting.

Safety, Certifications, and Warranty

The pole is manufactured to commercial standards for outdoor lighting support. All welds and structural components are designed for long-term reliability in exterior environments. The product includes a 1 year warranty covering material and workmanship.

EPA ratings are provided for wind speeds from 70 mph to 120 mph. Always confirm local code requirements and engineering standards for pole installation and foundation design. No additional certifications are specified for this product.

Frequently Asked Questions

Q: What is the maximum number of fixtures that can be mounted on this pole?

A: The maximum number depends on the total EPA and weight of the fixtures. The pole supports up to 9.6 EPA at 70 mph. Add the EPA of all fixtures and mounting hardware to ensure the total does not exceed the rated limit for your wind zone.

Q: What type of foundation is required for installation?

A: A concrete foundation with anchor bolts matching the 8 inch bolt circle and 3.375 inch projection is required. Foundation size and depth should be determined by a qualified engineer based on soil conditions and wind load.

Q: Is the pole suitable for coastal or high-salt environments?

A: The hot dip galvanized and powder coated finish provides corrosion resistance for standard outdoor use. In coastal or high-salt environments, additional maintenance or protective measures may be required to prevent corrosion at the base and anchor points.

Q: Can this pole be used for sports facility lighting?

A: Yes, the pole is commonly used for sports facility lighting where 30 foot mounting heights are needed. Confirm that the total EPA and fixture weight remain within rated limits for your application.

Q: How should fixture spacing be planned for parking lot applications?

A: Fixture spacing typically ranges from 80 to 120 feet, depending on light level requirements and fixture output. A photometric layout is recommended to determine optimal pole locations and achieve uniform coverage.

Application Questions and Clarification

Q: Is this pole compatible with both shoebox and flood light fixtures?

A: Yes, the included 2 3/8 inch tenon is compatible with standard slipfitter mounts used on most shoebox and flood light fixtures.

Q: What is the recommended maintenance schedule for this pole?

A: Inspect the pole, base plate, and anchor hardware annually for signs of corrosion or damage. Clean and touch up the finish as needed, especially in harsh environments.

Q: Are custom colors available beyond bronze, black, and white?

A: Standard color options are bronze, black, and white. Custom colors may be available by special request; consult with the manufacturer for lead times and availability.

Q: Can this pole be used in areas with wind speeds above 120 mph?

A: The maximum EPA rating is specified for up to 120 mph. For installations in areas with higher wind speeds, consult a structural engineer for site-specific requirements and consider alternative pole designs.
