25 Foot Round Fiberglass Light Pole | 5.75 Inch Diameter | Anchor Base
Product Description
Key Features
- Total Height: 25 Feet
- Material: Fiberglass
- Pole Weight: 75 lbs
- Pole Diameter: 5.75 Inch Base | 5.3 in Tip
- Pole Bolt Circle: 8 to 9.5 Inches
- Pole Finish: Acrylic Enamel
- Pole Color: Bronze | Custom
- Bolt Projection: 2.75 in
- Pole Installation: Anchor Base
- Bolt Size: 3/4 in x 24 in w / 3 in leg | 4 in thread
- Warranty: 15 years
- EPA at 70 mph: 4.5
- EPA at 80 mph: 4
- EPA at 90 mph: 3.5
- EPA at 100 mph: 3
Our 25 foot round fiberglass light poles are 5.75 inches round. These poles are perfect for adding area lighting like decorative or standard post top fixtures. These poles come with a 15-year warranty. This pole is rated at 3 EPA at 100 mph.
Disclaimer: LED Lighting Supply is not responsible for improper loading of light fixtures or other attachments, improper use, or foundation design of light poles. We act solely as a supplier of lighting solutions, including metal halide replacement fixtures and parking lot light poles. Final pole assembly and installation are the responsibility of the purchaser.
Dimensions and specifications for round or square composite light poles are subject to change without notice. Please refer to the current data sheet for the most up-to-date specifications. Custom sizing is available only for large-quantity orders. Pole caps may be used in place of other mounting options when required.
Composite light poles are covered by a 15-year workmanship warranty, which warrants that the poles are free from manufacturing defects-including weld and structural integrity issues-at the time of shipment. Any pole found to be defective, upon examination, during normal use and service within 15 years from the date of shipment will be repaired or replaced at our discretion. This warranty does not cover damage resulting from external factors, misuse, or normal wear and tear.
Web ID: 2332
Product Overview
This 25-foot round fiberglass light pole measures 5.75 inches at the base, tapering to 5.3 inches at the tip. The pole weighs 75 pounds and uses an anchor base installation method with 3/4-inch by 24-inch anchor bolts featuring a 3-inch leg and 4-inch thread. Bolt projection is 2.75 inches, with a bolt circle ranging from 8 to 9.5 inches.
The pole ships with an acrylic enamel finish in bronze, with custom color options available. This fiberglass construction carries a 15-year warranty.
Where This Product Fits Best
This pole is designed for area lighting applications using decorative or standard post top fixtures. The 25-foot height and fiberglass construction make it suitable for parking areas, pathways, building perimeters, and other outdoor spaces requiring elevated fixture mounting.
Fiberglass poles are commonly selected for locations where corrosion resistance matters or where reduced weight simplifies handling during installation. The 75-pound weight allows smaller crews to manage positioning compared to equivalent steel or aluminum poles.
Performance and Functional Considerations
Wind load capacity is rated by effective projected area (EPA) at various wind speeds. This pole supports 4.5 EPA at 70 mph, 4 EPA at 80 mph, 3.5 EPA at 90 mph, and 3 EPA at 100 mph. Fixture selection must account for these EPA limits based on the wind conditions at the installation site.
The tapered profile from 5.75 inches at the base to 5.3 inches at the tip is standard for round fiberglass poles and contributes to overall structural performance under wind loading.
Installation and Long-Term Use
This pole uses an anchor base mounting system. The anchor bolt specification is 3/4-inch diameter by 24 inches long with a 3-inch leg and 4-inch thread. Bolt projection above the foundation is 2.75 inches, and the bolt circle diameter ranges from 8 to 9.5 inches. Foundation design must accommodate these dimensions.
The acrylic enamel finish provides the exterior surface protection. Fiberglass does not rust or corrode in the manner of ferrous metals, which reduces long-term maintenance concerns in humid, coastal, or chemically exposed environments.
How This Fixture Is Commonly Used
Facilities use this pole to mount post top fixtures for parking lot lighting, walkway illumination, and general area lighting around commercial or institutional properties. The 25-foot height positions fixtures above pedestrian and vehicle traffic while providing appropriate coverage angles for ground-level illumination.
When selecting fixtures, verify that the combined EPA of the luminaire and any mounting hardware does not exceed the pole''s rated capacity at the expected wind speed for your location. For sites in higher wind zones, the 3 EPA limit at 100 mph becomes the controlling factor for fixture selection.
Safety, Certifications, and Warranty
This pole carries a 15-year warranty.
The pole is available in bronze as the standard finish, with custom color options available upon request.
Frequently Asked Questions
What anchor bolts are required for this pole?
The pole uses 3/4-inch by 24-inch anchor bolts with a 3-inch leg and 4-inch thread. Bolt projection is 2.75 inches, with a bolt circle of 8 to 9.5 inches.
What is the EPA rating at 100 mph?
This pole is rated at 3 EPA at 100 mph wind speed.
How much does the pole weigh?
The pole weighs 75 pounds.
What finish options are available?
The pole is finished in acrylic enamel and available in bronze or custom colors.
What is the warranty coverage?
This pole includes a 15-year warranty.
Application Questions and Clarification
This product description reflects the provided specifications, ratings, and configuration options. For questions related to site-specific conditions, electrical compatibility, control integration, or application requirements not addressed in the provided data, our team is available to provide clarification.
