25 Foot Above Grade | 29.5 Foot Total Height Square Fiberglass Light Pole | 4 Inches Wide | Direct Burial
This 29.5-foot fiberglass light pole is a strong choice for outdoor environments where durability, safety, and ease of installation are priorities. Its lightweight construction simplifies handling and direct burial installation, reducing labor costs. The non-conductive, corrosion-resistant fiberglass with a fluoropolymer coating ensures long service life in harsh weather, while EPA ratings up to 90 mph and the ability to bend without breaking provide reliability in high wind areas. The pole's fire resistance and 7-year warranty further support its use in parking lots, outdoor yards, sports fields, and other exposed commercial or industrial sites.
Neil Peterson | CEO and Chief Lighting Specialist
Out of stock
Product Specifications
Key Features
| Brand | LED Lighting Supply |
| Total Height (ft) | 29.5 |
| Height Above Grade (ft) | 25 |
| Buried Depth Below Grade (ft) | 4.5 |
| Material | Fiberglass |
| Pole Weight (lbs) | 80 |
| Pole Width (in) | 4 |
| Pole Finish | Fluoropolymer Coating |
| Pole Color | Bronze | Black | White | Gray | Custom |
| Pole Installation | Direct Burial |
| Includes | Top Cap |
| Gauge | .25 in |
| EPA Rating 70 mph | 7.6 |
| EPA Rating 80 mph | 4.6 |
| EPA Rating 90 mph | 2.5 |
| Warranty | 7 years |
Benefits:
- Lightweight, easier to unload and install, saving on labor costs
- Does not rot, rust, or corrode.
- Non-conductive
- Does not break down with age, coated in 25-year UV protective paint
- Stronger than equivalent steel in compression and tension, providing excellent durability and longevity in high wind conditions
- Designed to bend, not break, meaning that poles can naturally bend due to weather conditions and will return to their original form
- Fire resistance: poles do not sustain a flame, as there is no fuel source for fire
Disclaimer: LED Lighting Supply is not responsible for improper loading of light fixtures or other attachments, use, or foundation design of light poles. We are solely a supplier of lighting solutions, metal halide replacement lights, and poles for parking lots. Final pole assembly is the responsibility of the purchaser. Dimensions and specifications of a round or square composite light pole are subject to change without notice. See the data sheet for current pole data charts. Custom sizing is only available for large order quantities. Pole caps are used in place of other mounting options when necessary.
Please be advised that our composite poles are covered solely by a 7-year workmanship warranty, which ensures that the poles are free from defects from the manufacturing process. This warranty does not cover damage resulting from external factors, misuse, or normal wear and tear.
Product Overview
This square fiberglass light pole provides 25 feet of height above grade with a direct burial installation. Its total length is 29.5 feet, including 4.5 feet below grade.
The pole has a 4-inch width, 0.25-inch gauge, and 80-pound weight. It is intended for outdoor pole-mounted lighting layouts where a non-conductive fiberglass structure is required.
Core Performance and Output
This pole supports EPA ratings of 7.6 at 70 mph, 4.6 at 80 mph, and 2.5 at 90 mph. Fixture weight and EPA requirements must remain within the applicable rating for the project wind speed.
The fiberglass structure is designed to flex under weather loading and return to its original form. The 25-foot above-grade height supports elevated site and field lighting layouts, but the pole does not establish fixture output, beam distribution, or lighting coverage.
Adjustability and Control Options
This is a fixed-height direct burial pole with no height adjustment after installation. Final above-grade height is determined by the 4.5-foot burial depth.
Lighting controls, fixture controls, and electrical components are not included in the supplied product data. Control equipment must be selected separately based on the installed fixture and project requirements.
Longevity and Reliability
The fiberglass construction does not rot, rust, or corrode. The pole has a fluoropolymer coating with 25-year UV protective paint.
The material is non-conductive and fire resistant. It does not sustain a flame because it does not provide a fuel source for fire.
Build Quality and Physical Characteristics
This pole is constructed from fiberglass with a square 4-inch profile. It weighs 80 pounds and includes a top cap.
Available pole colors are bronze, black, white, gray, and custom. The direct burial design requires excavation and installation below grade rather than a base-mounted foundation connection.
Where This Product Fits Best
This pole fits outdoor lighting installations requiring a fiberglass structure with direct burial installation and a 25-foot above-grade mounting position. Its corrosion-resistant and non-conductive construction aligns with exposed outdoor conditions.
- baseball field lighting
- soccer field lighting
- roadway lighting
- campus lighting
- coastal lighting
- wastewater facility lighting
EPA capacity must be checked against fixture EPA, fixture weight, wind speed, and mounting configuration. The pole is also suited to locations where rust and corrosion are ongoing maintenance concerns.
Installation and Long-Term Use
Installation requires direct burial with 4.5 feet of the pole below grade, leaving 25 feet above grade. Site excavation, pole alignment, and backfill conditions affect final pole position and long-term stability.
The 80-pound fiberglass construction is lighter than many comparable structural pole materials during handling. Fixture loading must be confirmed before installation against the applicable EPA rating.
How This Fixture Is Commonly Used
In baseball field lighting, soccer field lighting, and other sports field lighting layouts, the pole provides a 25-foot above-grade fixture mounting position. In roadway lighting and campus lighting layouts, poles are placed according to the required coverage pattern and site geometry.
Spacing and fixture count vary with the selected fixture output, optic, target light levels, and layout requirements. Higher fixture output can reduce pole quantity, but fixture EPA must remain within the pole rating for the site wind speed.
Safety, Certifications, and Warranty
This fiberglass pole is non-conductive and fire resistant. It is designed to bend under weather conditions rather than break.
The pole includes a 7-year warranty.
Frequently Asked Questions
Q: What is the installed height of this fiberglass light pole?
A: The pole provides 25 feet of height above grade. Its total length is 29.5 feet, including 4.5 feet intended for below-grade burial.
Q: What are the EPA ratings for this pole?
A: The EPA rating is 7.6 at 70 mph, 4.6 at 80 mph, and 2.5 at 90 mph.
Q: How is this pole installed?
A: This pole uses direct burial installation. The supplied data identifies a 4.5-foot buried depth below grade.
Q: Is the pole suitable for corrosive environment lighting?
A: Fiberglass construction does not rot, rust, or corrode. Corrosive environment lighting is included within the valid applications for fiberglass light and utility poles.
Q: What factors affect pole layout for sports field lighting?
A: Fixture output, optic, target light levels, fixture EPA, wind speed, and layout requirements affect the final pole layout. The supplied data does not establish a specific pole spacing or fixture count.
Application Questions and Clarification
Q: Can this pole be used for coastal lighting and marina lighting?
A: Coastal lighting and marina lighting are valid applications for fiberglass light and utility poles. The fiberglass material does not rot, rust, or corrode.
Q: What should be verified before mounting fixtures for roadway lighting?
A: Verify the fixture weight and EPA against the pole EPA rating for the applicable wind speed. The pole is rated at 7.6 EPA at 70 mph, 4.6 EPA at 80 mph, and 2.5 EPA at 90 mph.
Q: Does this pole support a fixed above-grade height for campus lighting?
A: Yes. Direct burial installation with 4.5 feet below grade provides 25 feet of pole height above grade.
Web ID: 2333
