50 / 60 / 80 Watt Adjustable LED Wall Pack | 7750 to 12400 Lumens | 3000K / 4000K / 5000K Adjustable | 100-277V | Built-In Photocell

Product Overview

This adjustable LED wall pack is designed for exterior wall mounting on commercial and industrial buildings. It provides selectable wattage (50W, 60W, or 80W) and color temperature (3000K, 4000K, or 5000K) to match site requirements. Typical use includes replacing 250W metal halide wall packs on building perimeters, service areas, and loading zones.

The fixture includes a built-in photocell for dusk-to-dawn operation and is suitable for mounting heights from 8 to 18 feet. The housing is die-cast aluminum with a polycarbonate lens, supporting long-term use in outdoor environments.

Core Performance and Output

This wall pack delivers 7750 to 12400 lumens, depending on the selected wattage. Efficacy is 155 lumens per watt. The 110° Type 4 distribution provides wide, even coverage along building exteriors and perimeter walkways. Power factor is greater than 0.90, and total harmonic distortion is less than 20%.

Output is suitable for most exterior wall applications, but may be excessive for small entryways or low mounting heights below 8 feet. At higher mounting heights above 18 feet, uniformity and ground-level light levels may decrease.

Adjustability and Control Options

Wattage and color temperature can be set during installation using onboard switches. This allows tuning for site-specific light levels and color requirements. The fixture supports 1-10V dimming for integration with external controls if needed.

A built-in photocell enables automatic dusk-to-dawn operation. The photocell can be bypassed if manual or time-based control is preferred.

Longevity and Reliability

L70 rated life is 50,000 hours. The fixture is designed for continuous outdoor use, with an IP65 rating for protection against dust and water jets. Operating temperature range is -40°F to 122°F.

All components are housed in a sealed die-cast aluminum enclosure to prevent moisture ingress and corrosion. The polycarbonate lens resists impact and UV degradation.

Build Quality and Physical Characteristics

The fixture measures 14 x 9 x 7.1 inches and weighs 10.3 lbs. The housing is bronze-finished die-cast aluminum. The lens is clear polycarbonate for maximum light output and durability.

Wall mounting is supported with a standard backplate. All wiring and adjustment points are accessible from the rear for straightforward installation and maintenance.

Where This Product Fits Best

This wall pack is intended for exterior wall mounting on commercial and industrial buildings. It is suitable for perimeter lighting, security coverage, and building facade illumination. The adjustable output and color temperature allow use across a range of exterior applications.

• security lighting
• building facade lighting
• building exterior lighting
• commercial exterior wall lighting
• perimeter lighting
• entry lighting
• service area lighting
• loading area lighting

IP65 rating and wide operating temperature range support use in exposed outdoor locations. The fixture is not intended for canopy, ceiling, or pole mounting.

Installation and Long-Term Use

Wall mounting is direct to flat exterior surfaces using the included backplate. All wiring is completed from the rear. The fixture supports 100-277V input for compatibility with standard commercial circuits.

Routine maintenance is limited to periodic cleaning of the lens and inspection of seals. Adjustment of wattage or color temperature requires access to the internal switches. The built-in photocell can be disabled if site controls require override.

How This Fixture Is Commonly Used

Typical mounting height is 8 to 18 feet above grade. Spacing between fixtures varies based on wattage setting and required light levels, but is commonly 20 to 40 feet for perimeter and security applications.

Fixtures are often installed in continuous runs along building exteriors, at entry points, or above loading docks. Higher output settings reduce fixture count but may increase glare if mounted at lower heights.

Safety, Certifications, and Warranty

This fixture is UL listed and IP65 rated. It is eligible for utility rebates where applicable. The product includes a 5-year warranty covering manufacturing defects and performance.

All electrical and mechanical components are designed for safe operation in outdoor commercial environments. No special maintenance procedures are required beyond standard inspection and cleaning.

Frequently Asked Questions

Q: What is the recommended mounting height for this wall pack?

A: Recommended mounting height is 8 to 18 feet above grade for optimal coverage and uniformity.

Q: Can the wattage and color temperature be changed after installation?

A: Wattage and color temperature can be adjusted by accessing the internal switches. Power must be disconnected before making changes.

Q: Is the built-in photocell required to be used?

A: The photocell can be bypassed if manual or external control is preferred.

Q: What is the expected lifespan of this fixture?

A: The fixture is rated for 50,000 hours (L70) under normal operating conditions.

Q: How should fixtures be spaced for perimeter lighting?

A: Spacing typically ranges from 20 to 40 feet, depending on wattage setting and required light levels.

Application Questions and Clarification

Q: Is this wall pack suitable for use in loading area lighting?

A: Yes, the output and distribution are appropriate for loading area and service area wall mounting.

Q: Can this fixture be used for multifamily exterior lighting?

A: Yes, it is suitable for multifamily building exteriors, including perimeter and entry lighting.

Q: Is this fixture appropriate for alley lighting?

A: The fixture can be used for alley lighting when wall mounted at appropriate heights and spacing.

Q: Is this product intended for canopy or ceiling mounting?

A: No, this fixture is designed for wall mounting only and is not intended for canopy or ceiling installations.
