30 / 45 / 63 Watt Adjustable Semi Cutoff LED Wall Pack | 4200 to 8800 Lumens | 3000K / 4000K / 5000K Adjustable | 100-277V | Built-In Photocell

Product Overview

This adjustable semi cutoff LED wall pack is designed for versatile exterior lighting applications, offering wattage options of 30, 45, and 63 watts. It delivers between 4200 and 8800 lumens, making it suitable for a range of outdoor environments. The fixture is equipped with a built-in photocell for automatic dusk-to-dawn operation, enhancing energy efficiency. With color temperature adjustability between 3000K, 4000K, and 5000K, it provides flexibility in achieving the desired ambiance and visibility.

Constructed with a die-cast aluminum housing and a polycarbonate lens, this wall pack is built to withstand harsh weather conditions. It is UL listed and IP65 rated, ensuring reliable performance in wet locations. The fixture is ideal for replacing traditional 250-watt metal halide fixtures, offering significant energy savings and reduced maintenance costs over its lifespan.

Core Performance and Output

The LED wall pack offers three adjustable wattage settings, providing lumen outputs of 4200, 6300, and 8800 lumens. This flexibility allows for tailored lighting solutions depending on the specific needs of the installation site. With an efficacy of 134 lumens per watt, it ensures efficient energy use while maintaining high light output.

The fixture's beam distribution is designed to provide uniform illumination across building facades and pathways. However, at lower mounting heights, the highest wattage setting may produce excessive brightness, potentially causing glare. Conversely, at higher mounting heights, the lowest wattage setting may result in reduced uniformity.

Adjustability and Control Options

This wall pack features both wattage and color temperature adjustability, allowing for customization based on the specific lighting requirements of the application. The built-in photocell enables automatic on/off functionality, optimizing energy use by ensuring the fixture operates only when needed.

While the fixture does not support dimming, the adjustable settings provide sufficient control over light output and color temperature to meet most exterior lighting needs. The photocell integration further enhances control by automating the lighting schedule.

Longevity and Reliability

Designed for long-term use, this LED wall pack has a rated lifespan of 50,000 hours (L70), ensuring years of reliable operation with minimal maintenance. The robust construction and IP65 rating protect the fixture from dust and water ingress, making it suitable for outdoor environments.

The fixture includes surge protection up to 4kV, safeguarding it against voltage spikes and ensuring consistent performance. With a power factor greater than 0.9 and a total harmonic distortion of less than 20%, it operates efficiently and reliably in various electrical systems.

Build Quality and Physical Characteristics

The wall pack's housing is made from die-cast aluminum, providing durability and resistance to corrosion. Its polycarbonate lens is impact-resistant, offering additional protection against vandalism and environmental damage. The fixture's bronze finish complements most building exteriors, providing a cohesive aesthetic.

Weighing 6.2 pounds and measuring 14.3 x 9.3 x 5.6 inches, the fixture is compact and easy to install on most exterior walls. Its design ensures it can withstand operating temperatures ranging from -40°F to 113°F, making it suitable for diverse climates.

Where This Product Fits Best

This LED wall pack is best suited for environments requiring reliable and efficient exterior lighting. Its adjustable features make it adaptable to various settings, providing optimal illumination for safety and security.

• security lighting
• building facade lighting
• commercial exterior wall lighting
• perimeter lighting
• entry lighting

The fixture's IP65 rating and robust construction make it ideal for outdoor use, ensuring performance in wet and dusty conditions. Its adjustable wattage and color temperature settings allow for tailored lighting solutions, enhancing visibility and security in these environments.

Installation and Long-Term Use

Installation of this wall pack is straightforward, with wall mounting as the primary method. The fixture's compact size and light weight facilitate easy handling and positioning during installation. It is designed for use with standard 100-277V electrical systems, ensuring compatibility with most commercial and industrial setups.

For long-term use, regular cleaning of the lens and housing is recommended to maintain optimal light output and appearance. The fixture's durable construction minimizes the need for frequent maintenance, reducing overall operational costs.

How This Fixture Is Commonly Used

This LED wall pack is commonly mounted at heights ranging from 8 to 15 feet, providing effective illumination for building exteriors and pathways. The spacing between fixtures can vary based on the wattage setting and desired light levels, with higher outputs allowing for greater distances between units.

In applications where higher output is used, fewer fixtures may be needed, but care should be taken to manage potential glare. Conversely, lower output settings may require more fixtures to achieve uniform coverage, particularly in larger areas.

Safety, Certifications, and Warranty

This LED wall pack is UL listed, ensuring compliance with safety standards for electrical products. It is also rebate eligible, providing potential cost savings through energy efficiency programs. The fixture's IP65 rating certifies its suitability for wet locations, offering reliable performance in outdoor environments.

A 5-year warranty covers the fixture, providing assurance of its quality and durability. This warranty supports long-term use and helps mitigate concerns about potential defects or performance issues.

Frequently Asked Questions

Q: What is the maximum mounting height for this wall pack

A: The recommended mounting height ranges from 8 to 15 feet, depending on the wattage setting and desired light coverage.

Q: Can the color temperature be adjusted after installation

A: Yes, the color temperature can be adjusted between 3000K, 4000K, and 5000K even after installation.

Q: Does this fixture support dimming

A: No, this fixture does not support dimming. However, it offers adjustable wattage and color temperature settings for customization.

Q: Is the fixture suitable for coastal environments

A: While the fixture is IP65 rated for wet locations, it is not specifically designed for corrosive coastal environments.

Application Questions and Clarification

Q: What are the primary applications for this LED wall pack

A: Primary applications include security lighting, building facade lighting, and commercial exterior wall lighting.

Q: Can this fixture be used for entry lighting

A: Yes, it is suitable for entry lighting, providing adequate illumination for doorways and access points.

Q: Is this fixture appropriate for perimeter lighting

A: Yes, it can be effectively used for perimeter lighting, enhancing security and visibility around building exteriors.
