150 Watt LED Wall Pack | 19500 Lumens | 5000K | 100-277V | Built-In Photocell

Product Overview

This 150-watt LED wall pack provides 19,500 lumens of 5000K exterior light from a wall-mounted die-cast aluminum fixture. It uses a 120-degree distribution and a polycarbonate lens for broad forward illumination.

The fixture is configured for building-mounted exterior lighting where higher output is needed along walls, entries, perimeters, and loading areas. It operates on 100-277V power and includes a built-in photocell.

Core Performance and Output

This wall pack delivers 19,500 lumens at 130 lumens per watt. The 5000K color temperature and 70+ CRI support clear exterior visibility, while the 120-degree beam angle provides a wide distribution from a wall-mounted position.

The fixture operates at 100-277V, 50/60 Hz, with a power factor above 0.90 and THD below 20%. Its output is substantial for low mounting locations and should be evaluated against glare and light levels near entries or pedestrian areas.

Adjustability and Control Options

The fixture supports 1-10V dimming. Control wiring and dimming compatibility need to be confirmed as part of the project electrical design.

A built-in photocell is included for daylight-responsive operation. The photocell supports automatic on and off operation based on ambient light conditions.

Longevity and Reliability

This LED wall pack is rated for a 50,000-hour lifespan and carries a 5-year warranty. The operating temperature range is -40 degrees F to 122 degrees F.

The solid-state LED configuration avoids lamp replacement associated with the stated 400-watt metal halide replacement application. Long-term performance still depends on stable electrical connections, suitable controls, and maintaining the lens surface.

Build Quality and Physical Characteristics

The fixture has a bronze die-cast aluminum housing and a polycarbonate lens. It is IP65 rated.

Overall dimensions are 18.3 x 9.3 x 9 inches, and the fixture weighs 10 pounds. Wall mounting is the specified installation method.

Where This Product Fits Best

This fixture fits exterior wall locations that need broad, high-output illumination from a building-mounted fixture. Its IP65 rating and operating temperature range support exposed exterior conditions within the stated limits.

• building exterior lighting
• security lighting
• commercial exterior wall lighting
• building facade lighting
• perimeter lighting
• loading area lighting
• entry lighting

The 120-degree distribution works best where light needs to project outward from a wall rather than follow a narrow path. Wall location, mounting height, adjacent surfaces, and the desired illuminated area affect the final layout.

Installation and Long-Term Use

This fixture mounts directly to a wall and requires support for its 10-pound fixture weight. Verify wall condition, junction box arrangement, conductor routing, and 100-277V supply before installation.

Position the fixture so the photocell is exposed to representative ambient daylight and not affected by nearby fixture light. Maintain access for future inspection of electrical connections, lens condition, and controls.

How This Fixture Is Commonly Used

In building exterior lighting, security lighting, and commercial exterior wall lighting layouts, fixtures are placed along wall runs to project light away from the structure. Mounting height is determined by wall geometry, target light levels, and the area requiring coverage.

For perimeter lighting, loading area lighting, and entry lighting, layout patterns typically follow access points, wall corners, and exterior travel routes. Higher output can reduce fixture count, but wider spacing can reduce uniformity between fixtures.

Safety, Certifications, and Warranty

This fixture is ETL listed. It is rebate eligible.

The fixture is IP65 rated and has a 5-year warranty. Its stated operating temperature range is -40 degrees F to 122 degrees F.

Frequently Asked Questions

Q: What light output does this LED wall pack provide?

A: It provides 19,500 lumens at 150 watts, with an efficacy of 130 lumens per watt.

Q: What voltage does this fixture operate on?

A: The fixture operates on 100-277V, 50/60 Hz power.

Q: Does this wall pack include a photocell?

A: Yes. A built-in photocell is included.

Q: Can this fixture be dimmed?

A: Yes. It supports 1-10V dimming.

Q: What should be considered when planning fixture layout?

A: Mounting height, wall location, target light levels, the 120-degree beam distribution, and layout requirements affect fixture placement. A specific spacing value is not established by the supplied product data.

Application Questions and Clarification

Q: Is this fixture suitable for loading area lighting?

A: Loading area lighting is a valid application for this wall pack. Final placement depends on wall location, mounting height, and required light distribution.

Q: What should be reviewed for security lighting applications?

A: Review fixture location, mounting height, 120-degree beam distribution, target light levels, and photocell exposure. The fixture provides 19,500 lumens at 5000K.

Q: Can this fixture be used for building facade lighting?

A: Building facade lighting is a valid application. The wall-mounted configuration and 120-degree beam distribution should be evaluated against the required facade coverage and light direction.
