15 Watt Semi Cutoff LED Wall Pack | 1950 Lumens | 5000K | 100-277V

Product Overview

The 15 Watt Semi Cutoff LED Wall Pack is designed for exterior wall mounting where moderate light levels and controlled distribution are required. This fixture delivers 1950 lumens at 5000K, providing clear, neutral-white illumination for building perimeters and entry points. The semi cutoff design limits uplight and reduces glare, making it suitable for security and pathway lighting along commercial and multifamily exteriors.

This wall pack is a direct replacement for legacy 70W metal halide units, offering improved efficiency and lower maintenance. Typical mounting heights range from 7 to 10 feet on exterior walls, service areas, and building entrances.

Core Performance and Output

This fixture outputs 1950 lumens at 15 watts, achieving 130 lumens per watt. The 120x90° beam angle provides wide, even coverage along building facades and walkways. Color temperature is 5000K with a CRI above 70, supporting clear visibility for security and wayfinding tasks.

Power factor exceeds 0.90 and THD is below 20%, ensuring stable electrical performance on 100-277V circuits. Output is best suited for low to mid-height mounting; excessive brightness may occur if installed below 7 feet. Uniformity may decrease if spacing exceeds typical wall pack intervals.

Adjustability and Control Options

This wall pack is a fixed-output fixture with no integrated dimming or motion control. The semi cutoff optical design directs light forward and downward, minimizing uplight and spill. No field-adjustable beam or color settings are included.

Control integration is limited to external switching or circuit-based controls. Photocell or occupancy sensor compatibility depends on external device selection and installation method.

Longevity and Reliability

L70 rated life is 50,000 hours, supporting multi-year operation in demanding exterior environments. The fixture is IP65 rated for dust and water ingress, suitable for exposed outdoor locations.

Operating temperature range is -40°F to 113°F. The LED driver and components are protected within a sealed die-cast aluminum housing, reducing risk of failure from weather or vandalism.

Build Quality and Physical Characteristics

The housing is constructed from die-cast aluminum with a bronze finish, providing impact resistance and corrosion protection. The lens is polycarbonate for additional vandal resistance and durability.

Fixture dimensions are 7.72 x 5.83 x 6.54 inches, with a total weight of 3.2 lbs. All mounting hardware is designed for standard wall installation. The compact form factor supports installation in tight or constrained exterior locations.

Where This Product Fits Best

This wall pack is intended for exterior wall mounting on commercial, multifamily, and service buildings where moderate light levels and vandal resistance are required. It is commonly used to illuminate building perimeters, entryways, and service areas at low to mid mounting heights.

• security lighting
• building facade lighting
• building exterior lighting
• commercial exterior wall lighting
• perimeter lighting
• entry lighting
• service area lighting
• multifamily exterior lighting

Suitable for outdoor environments exposed to rain, dust, and temperature extremes. The fixture is not intended for high-mount area lighting or applications requiring high output or advanced controls.

Installation and Long-Term Use

Wall mounting is supported using standard junction box patterns or direct surface mounting. The fixture?s compact size allows installation in areas with limited wall space or architectural constraints.

Routine maintenance is minimal due to the sealed housing and long LED life. Periodic cleaning of the lens and inspection of mounting hardware are recommended for optimal performance and safety. No relamping or internal servicing is required during normal operation.

How This Fixture Is Commonly Used

Typical mounting heights range from 7 to 10 feet along building exteriors, walkways, and service entrances. Spacing is generally 15 to 25 feet apart, depending on required light levels and site geometry.

Fixtures are often installed in continuous runs along perimeters or grouped at entry points for targeted illumination. Higher output reduces fixture count but may increase glare if mounted too low or spaced too closely.

Safety, Certifications, and Warranty

This fixture is ETL certified and IP65 rated. It is suitable for wet locations and meets requirements for exterior commercial lighting. The product is rebate eligible where applicable.

A 5-year warranty covers manufacturing defects and component failure under normal use. All safety and certification markings are present on the fixture label.

Frequently Asked Questions

Q: What is the recommended mounting height for this 15W wall pack?

A: Recommended mounting height is 7 to 10 feet for optimal coverage and uniformity.

Q: Can this fixture be used with a photocell or motion sensor?

A: The fixture does not include integrated controls but can be used with external photocells or sensors installed on the circuit.

Q: Is this wall pack suitable for high-traffic or vandal-prone areas?

A: Yes, the die-cast aluminum housing and polycarbonate lens provide vandal resistance for exterior installations.

Q: How many fixtures are needed for a 100-foot building facade?

A: Spacing at 20-foot intervals is typical, so five fixtures would provide even coverage along a 100-foot wall.

Application Questions and Clarification

Q: Is this fixture appropriate for lighting exterior service areas and building entries?

A: Yes, it is commonly installed at service doors, loading areas, and building entries for security and wayfinding.

Q: Can this wall pack be used for perimeter lighting on multifamily buildings?

A: Yes, it is suitable for multifamily exterior perimeter lighting at low to mid mounting heights.

Q: Is this product intended for general area lighting or parking lot illumination?

A: No, this wall pack is designed for wall-mounted exterior lighting, not for pole-mounted area or parking lot applications.
