400 / 500 / 600 Watt Adjustable Round LED Stadium Light | 68000 to 105000 Lumens | 5000K | 100-277V or 200-480V

Product Overview

This LED flood light offers adjustable wattage settings of 90, 120, or 150 watts and selectable color temperatures of 3000K, 4000K, or 5000K. Output ranges from 15,750 to 26,250 lumens, supporting a wide range of exterior and area lighting needs.

The fixture is built with a heavy-duty die-cast aluminum housing, finished with an anti-corrosion powder coat. It is available with either a yoke or slipfitter mount for installation flexibility.

A built-in button photocell is included and can be turned off if not required. The fixture operates on 100-277V input and is designed for maintenance-free operation over a long service life.

Tempered glass optics, a 120° beam angle, and a CRI of 80+ support consistent, high-quality illumination in demanding environments.

Where This Product Fits Best

This fixture is suitable for replacing 250 or 400 watt metal halide flood lights in exterior or area lighting applications. The adjustable wattage and color temperature allow for adaptation to site-specific requirements.

It is designed for use in environments where exposure to dust, water, and physical impact is expected. The IP66 and IK07 ratings support use in outdoor and industrial settings.

Mounting options include yoke and slipfitter, making it compatible with wall, pole, or surface installations. The EPA rating of 0.95 supports use in locations where wind load is a consideration.

The fixture is appropriate for facilities operating within a voltage range of 100-277V and ambient temperatures from -40°F to 122°F.

Performance and Functional Considerations

The wattage and color temperature can be set during installation to match site lighting requirements. Output levels of 15,750, 21,000, or 26,250 lumens provide flexibility for different coverage needs.

The fixture delivers 175 lumens per watt and maintains a power factor of 0.9 with total harmonic distortion at 15%. The 120° beam angle supports wide area coverage.

Surge protection is rated at 6KV line-line and 10KV line-earth, supporting operation in areas with electrical disturbances. The fixture is non-dimmable.

The tempered glass lens and powder-coated aluminum housing are designed for durability and long-term reliability in harsh conditions.

Installation and Long-Term Use

The fixture weighs 8 lbs and measures 10.2 inches wide by 11.2 inches high by 2.6 inches deep. A 16-inch cord is provided for wiring connections.

Yoke and slipfitter mounting options allow for installation on a variety of surfaces and poles. The fixture color is bronze, matching common exterior hardware.

The IP66 rating allows for installation in locations exposed to heavy rain, dust, and water jets. The IK07 rating supports resistance to moderate physical impact.

Operating temperature range is -40°F to 122°F, supporting use in both cold and hot climates. The fixture is designed for maintenance-free operation over a rated lifespan of 164,000 hours (L70).

How This Fixture Is Commonly Used

After installation, you can set the wattage and color temperature to match the lighting requirements of your site. This allows you to adjust output and appearance as needed for different areas or changing conditions.

The built-in photocell can be enabled or disabled depending on whether you want the fixture to operate automatically based on ambient light. Once set, the fixture operates without further adjustment.

The wide beam angle provides broad, even coverage for parking lots, building perimeters, or general area lighting. The fixture is typically left in place for years without the need for routine maintenance.

Physical durability and environmental protection ratings allow the fixture to be relied on in exposed locations, including areas subject to rain, dust, and occasional impact.

Safety, Certifications, and Warranty

This fixture is ETL listed and DLC Premium qualified.

The IP66 rating allows the fixture to withstand high-pressure water jets and heavy dust exposure. The IK07 rating supports resistance to moderate impact from objects or equipment.

Surge protection is built in to handle electrical disturbances up to 6KV line-line and 10KV line-earth.

LED Lighting Supply provides a 5-year warranty on this fixture.

Frequently Asked Questions

What voltage does this fixture support?
This fixture operates on 100-277V input.

What is the lumen output range?
Lumen output is adjustable from 15,750 to 26,250 lumens, depending on the selected wattage.

What mounting options are available?
Yoke and slipfitter mounting options are available.

What certifications does this fixture carry?
This fixture is ETL listed and DLC Premium qualified.

What is the warranty period?
LED Lighting Supply provides a 5-year warranty.

What environmental conditions can this fixture handle?
The fixture is rated for operation in temperatures from -40°F to 122°F and is protected against dust, water jets, and moderate impact.

Application Questions and Clarification

This product description reflects the provided specifications, ratings, and configuration options. For questions related to site-specific conditions, electrical compatibility, control integration, or application requirements not addressed in the provided data, our team is available to provide clarification.
