45 Watt Square Canopy Light | 6900 Lumens | 3000K / 4000K / 5000K Adjustable | 100-277V | Black Housing
Cory Peterson | VP of Marketing and Sales Operations
357 in stock
Product Specifications
Key Features
| Brand | LED Lighting Supply |
| Watts | 45 |
| Lumens | 6900 |
| Lumens Per Watt | 153 |
| Replaces | 250 Watt Metal Halide |
| Voltage | 100V-277V |
| Color Temperature | 3000K or 4000K or 5000K |
| CRI | 70+ |
| Dimming | 1-10V |
| Beam Angles (Std) | 90° |
| Optics | Polycarbonate Lens |
| Lifespan | 150,000 (L70) hours |
| Mounting | Pendant or Surface |
| Fixture Color | Black |
| Frequency (Hz) | 50/60 |
| Power Factor | .90 |
| THD | 20% Max |
Durable Construction
| Housing | Die-Cast Aluminum |
| IP Rating | IP65 |
| Surge Protection | 6kV |
| Operating Temperature | -4°F to 122°F |
| Certifications | UL | Rebate Eligible |
| Warranty | 5 years |
Measurements
| Dimensions (in) | 10 L X 10 W X 3 H |
| Weight (lbs) | 5 |
Features/Accessories
- Color Adjustable
- Motion Sensor
Download IES Files
Product Lighting Layout Estimator
Use this estimator to calculate approximate fixture count, spacing, and average foot-candles for a simple rectangular space using the selected LED fixture. Enter your room dimensions, mounting height, target foot-candles, light loss factor, and room/layout condition to generate a preliminary lighting layout. When IES photometry is available, workplane height and room reflectance controls are shown.
Project Inputs
Estimated Results
Estimated average foot-candles are preliminary and should be verified with a lighting plan for project-critical applications.
Room / Layout Condition: This field is used only when usable IES photometry is not available. In fallback mode, it acts as a simplified room utilization factor for reflectance, fixture distribution, racking, obstructions, and how much fixture light reaches the work area. Open / light-colored spaces use 0.90, typical warehouses or shops use 0.75, racked or obstructed spaces use 0.60, and dark or complex spaces use 0.45. When IES photometry is active, this field is hidden and the estimator uses the selected workplane height, LLF, and simplified reflectance adjustment instead.
Photometry / Simulation Note: When usable IES photometry is available for the selected fixture, this estimator uses the fixture’s IES candela data, selected workplane height, light loss factor, and simplified reflectance adjustment to estimate fixture count, average foot-candles, and visual light distribution. The reflectance adjustment is a conservative approximation and is not a full zonal-cavity, radiosity, or professional photometric room calculation. When IES photometry is not available, the estimator uses a simulated beam model based on lumens, mounting height, room/layout condition, light loss factor, and beam angle.
Preliminary Estimate Only: This estimator is intended for simple square or rectangular spaces and should be used as a planning aid, not a final photometric lighting plan. Actual light levels may vary based on fixture optics, selected IES file, mounting conditions, workplane height, ceiling height, surface reflectance, obstructions, controls, voltage, installation conditions, and site-specific requirements. Project-critical applications should be verified with a formal lighting plan.
This estimate is a starting point. Warehouses, industrial facilities, hazardous locations, sports areas, schools, healthcare spaces, public areas, and code-sensitive projects may require a reviewed lighting layout before purchase or installation.
Product Overview
This 45-watt square LED canopy light provides 6900 lumens with selectable 3000K, 4000K, and 5000K color temperature settings. It is built for pendant or surface installation below covered structures.
The compact 10-inch square housing fits gas station lighting, fueling area lighting, parking canopy lighting, and drive-through canopy lighting. Its listed 250-watt metal halide replacement rating supports LED conversion work where existing canopy fixture locations are retained.
Core Performance and Output
The fixture produces 6900 lumens at 153 lumens per watt. A 90-degree beam distribution directs light downward through a polycarbonate lens for covered lighting layouts.
It operates on 100-277V, 50/60Hz power with a 0.90 power factor and maximum 20% THD. The 6900-lumen output can be excessive where mounting heights are low or canopy areas are small.
Adjustability and Control Options
Field-selectable 3000K, 4000K, and 5000K settings allow the color temperature to be set for the installed location. The fixture supports 1-10V dimming.
A motion sensor option is available. Control selection should be established before installation so the fixture configuration matches the intended operating schedule and occupancy response.
Longevity and Reliability
The LED system is rated for 150,000 L70 hours. This rating supports long operating intervals in locations where fixture access requires work below a canopy or overhang.
The fixture includes 6kV surge protection and operates from -4 degrees F to 122 degrees F. Long-term performance still depends on proper electrical connections and maintaining the fixture enclosure.
Build Quality and Physical Characteristics
The housing is die-cast aluminum with a black finish. The polycarbonate lens protects the optical system while maintaining the 90-degree distribution.
This fixture measures 10 inches long by 10 inches wide by 3 inches high and weighs 5 pounds. Its IP65 rating supports exposure to outdoor conditions beneath the listed covered applications.
Where This Product Fits Best
This canopy light fits covered exterior locations that need downward-directed illumination from a compact surface-mounted or pendant-mounted fixture. The 45-watt output is suited to localized canopy lighting layouts rather than wide-area exterior lighting.
- gas station lighting
- fueling area lighting
- parking canopy lighting
- drive-through canopy lighting
- covered walkway lighting
- loading canopy lighting
- entry canopy lighting
The die-cast aluminum housing, IP65 rating, polycarbonate lens, and operating temperature range support covered outdoor exposure. Fixture placement should keep the lens clear of obstructions that interfere with the 90-degree beam pattern.
Installation and Long-Term Use
The fixture supports pendant or surface mounting. Verify the mounting surface, wiring method, voltage, and selected color temperature before final installation.
Surface mounting keeps the fixture close to the canopy structure, while pendant mounting lowers the fixture below the structure when the installation requires it. Periodic inspection should include the lens, mounting hardware, enclosure condition, and electrical connections.
How This Fixture Is Commonly Used
In gas station lighting, fueling area lighting, and parking canopy lighting, fixtures are generally arranged in rows or grid patterns based on canopy structure and required light distribution. Mounting height affects the spread of the 90-degree beam and the uniformity between fixture locations.
Drive-through canopy lighting, covered walkway lighting, loading canopy lighting, and entry canopy lighting commonly use fixture placement aligned with the covered path or service area. Wider spacing reduces fixture count but can reduce uniformity between fixtures.
Safety, Certifications, and Warranty
This fixture is UL listed and rebate eligible. It is IP65 rated.
The warranty is 5 years. The fixture includes 6kV surge protection.
Frequently Asked Questions
Q: What is the output of this canopy light?
A: The fixture uses 45 watts and produces 6900 lumens at 153 lumens per watt.
Q: What color temperatures are available?
A: The fixture has selectable 3000K, 4000K, and 5000K color temperature settings.
Q: What mounting methods are supported?
A: The fixture supports pendant mounting and surface mounting.
Q: Does this fixture support dimming and occupancy control?
A: The fixture supports 1-10V dimming and has a motion sensor option.
Q: What environmental rating does this fixture have?
A: The fixture is IP65 rated and has an operating temperature range of -4 degrees F to 122 degrees F.
Application Questions and Clarification
Q: Is this fixture appropriate for gas station lighting and fueling area lighting?
A: Gas station lighting and fueling area lighting are primary applications for this canopy light. The fixture provides 6900 lumens with a 90-degree beam distribution.
Q: Can this fixture be used for covered walkway lighting or entry canopy lighting?
A: Covered walkway lighting and entry canopy lighting are secondary applications. Pendant and surface mounting options support different covered structure conditions.
Q: What factors affect fixture placement for parking canopy lighting?
A: Mounting height, canopy structure, target light levels, and layout requirements affect fixture placement. A specific spacing value is not established by the supplied product data.
