60 / 80 / 100 Watt Adjustable LED Post Top Light | 7800 to 13000 Lumens | 3000K / 4000K / 5000K Adjustable | 100-277V

Product Overview

This is an adjustable LED post top light designed for outdoor area and site lighting. The fixture supports selectable wattages of 60, 80, or 100 watts and delivers up to 13,000 lumens. Color temperature can be set to 3000K, 4000K, or 5000K at installation. Typical use includes replacing 150W, 250W, or 400W metal halide post top fixtures on 3-inch poles in pedestrian areas, campuses, parks, and municipal sites.

The fixture is UL listed and IP65 rated for outdoor environments. It is suitable for mounting heights commonly found in pedestrian walkways, courtyards, and decorative site lighting applications.

Core Performance and Output

This post top fixture offers three selectable output levels: 7,800 lumens at 60W, 10,400 lumens at 80W, and 13,000 lumens at 100W. Delivered efficacy is 130 lumens per watt. The Type 5 distribution provides uniform 360-degree coverage, supporting even illumination in open areas and along pathways.

Color temperature can be field-adjusted to 3000K, 4000K, or 5000K to match site requirements. The fixture operates on 100-277V input and maintains a power factor above 0.92. At maximum output, mounting heights above 18 feet may reduce uniformity in smaller pedestrian zones.

Adjustability and Control Options

Both wattage and color temperature are adjustable via onboard switches, allowing field selection during installation. This supports tuning for site-specific light levels and color appearance. The fixture does not include dimming or integrated controls.

Type 5 optics are fixed and not field-changeable. No motion or daylight sensors are included. Control integration would require external devices or circuit-level switching.

Longevity and Reliability

The fixture is rated for 50,000 hours (L70) at ambient temperatures from -40°F to 113°F. The polycarbonate lens and die-cast aluminum housing provide resistance to impact and weather exposure. All electrical components are sealed against dust and water ingress to IP65 standards.

Thermal management is passive, with no moving parts. The fixture is designed for long-term operation in outdoor environments with minimal maintenance requirements.

Build Quality and Physical Characteristics

The housing is die-cast aluminum with a bronze finish. The lens is polycarbonate for impact resistance. The fixture mounts to standard 3-inch round poles and weighs 15.43 lbs. Overall dimensions are 16.5 inches in diameter by 17 inches in height.

EPA rating is 0.37, supporting use in typical post top and site lighting applications. The fixture is sealed to IP65 for outdoor use and is UL listed. No decorative shrouds or custom finishes are included.

Where This Product Fits Best

This fixture is designed for outdoor pedestrian and architectural site lighting. It is commonly used in environments where uniform area illumination and decorative appearance are required. The adjustable output and color temperature support deployment across a range of site types and lighting standards.

• post top lighting
• pedestrian area lighting
• decorative site lighting
• campus lighting
• park lighting
• municipal lighting
• courtyard lighting
• pathway lighting

The fixture is suitable for outdoor use in climates with wide temperature swings and regular precipitation. It is not intended for high-mast or large-area floodlighting.

Installation and Long-Term Use

The fixture mounts directly to 3-inch round poles using standard hardware. All wiring is completed at the pole base or within the pole shaft. Field adjustment of wattage and color temperature is completed prior to energizing the fixture.

Routine maintenance is limited to periodic cleaning of the lens and inspection of pole mounting hardware. No relamping or internal servicing is required during the rated life. The fixture is designed for straightforward replacement of legacy metal halide post tops.

How This Fixture Is Commonly Used

Typical mounting heights range from 10 to 18 feet, depending on site layout and desired light levels. Spacing between fixtures is determined by output setting and required uniformity, with closer spacing at lower wattages or for higher illumination standards.

Fixtures are often installed in linear runs along pathways or in clusters around plazas and courtyards. Higher output settings can reduce fixture count but may increase perceived brightness in small areas.

Safety, Certifications, and Warranty

This fixture is UL listed and IP65 rated. It meets requirements for outdoor wet location use. The product is eligible for utility rebates where applicable. A 5-year warranty covers manufacturing defects and component failure under normal operating conditions.

No hazardous location or marine certifications are included. The fixture is not rated for immersion or submersion.

Frequently Asked Questions

Q: What is the maximum mounting height for effective pedestrian area lighting with this fixture?

A: Mounting heights up to 18 feet are typical for pedestrian areas. Higher mounting may reduce uniformity and perceived brightness at ground level.

Q: Can the wattage and color temperature be changed after installation?

A: Wattage and color temperature can be adjusted at the fixture before energizing. Access to the fixture is required to change settings after installation.

Q: Is this fixture compatible with dimming controls?

A: This model does not support dimming. Output is set by the onboard wattage selector only.

Q: What is the recommended spacing for pathway or site lighting layouts?

A: Spacing varies by wattage and site requirements. Typical spacing is 2.5 to 3 times the mounting height for uniform coverage.

Q: Does the fixture include surge protection?

A: Surge protection is integrated to meet standard outdoor lighting requirements.

Application Questions and Clarification

Q: Is this fixture suitable for use in municipal parks and campus walkways?

A: Yes, the fixture is designed for park, campus, and municipal walkway lighting using post top mounting.

Q: Can this fixture be used for courtyard or decorative site lighting?

A: The fixture is commonly used for courtyard and decorative site lighting where uniform area illumination is needed.

Q: Is this product intended for roadway or parking lot lighting?

A: This fixture is not intended for roadway or large parking lot lighting. It is designed for pedestrian areas and architectural site lighting.

Q: What pole size is required for mounting?

A: The fixture mounts to standard 3-inch round poles.
