78 Inch HVLS Wall Mount Fan | 6 Blades | 43,370 CFM

Product Overview

This is a 16 foot diameter, 6-blade HVLS ceiling fan designed for large open spaces. The fan delivers up to 70,000 CFM and covers up to 12,750 square feet. It operates at a maximum speed of 44 RPM and produces less than 57 dBA of sound during operation.

The fan uses a 0.5 HP gear drive motor and is compatible with both single-phase and three-phase power. The wall-mounted VFD controller provides variable speed control, on/off toggle, and a safety disconnect. The fan weighs 126 lbs and is finished in black with aluminum blades.

Mounting options include I-Beam, Z-Purlins, and Open Joist. Downrod extensions are available in 1 ft, 2 ft, 3 ft, and 6 ft lengths to accommodate different ceiling heights and installation requirements.

Safety features include a safety cable, hub clips, hub retainer, dual-method fastening for all joined components, and an integrated sprinkler shut-off.

Where This Product Fits Best

This 16 foot HVLS fan is suited for industrial and commercial spaces with open layouts. Typical environments include warehouses, manufacturing facilities, distribution centers, aircraft hangars, and large workshops.

It is also used in gyms and other high-ceilinged spaces where broad air movement is needed. The fan is designed for installations where a minimum mounting height of 10 feet, minimum ceiling clearance of 6 feet, and minimum horizontal clearance of 2 feet can be met.

Facilities with I-Beam, Z-Purlin, or Open Joist structures can use the provided mounting options. The fan is compatible with 110V-120V, 208V-240V, and 460V-480V power supplies, supporting both single-phase and three-phase configurations.

Performance and Functional Considerations

The fan delivers up to 70,000 CFM, providing broad coverage for spaces up to 12,750 square feet. The variable speed controller allows adjustment to match airflow needs throughout the year.

With a maximum sound level below 57 dBA, the fan operates quietly in most environments. The 0.5 HP gear drive motor is sized for continuous operation in commercial and industrial settings.

Aluminum blades reduce weight and resist corrosion. The fan?s 6-blade design supports stable, efficient air movement at low speeds.

The wall-mounted VFD controller allows for direct, local control of fan speed and operation. Safety features are integrated into the mechanical and electrical design.

Installation and Long-Term Use

The fan can be mounted to I-Beam, Z-Purlin, or Open Joist structures. Downrod extensions in multiple lengths support installation at different ceiling heights while maintaining required clearances.

Minimum mounting height is 10 feet. At least 6 feet of ceiling clearance and 2 feet of horizontal clearance are required for safe operation and maintenance access.

The fan weighs 126 lbs. Installation requires secure structural attachment and electrical connection to the appropriate voltage and phase. The wall-mounted VFD controller should be installed within reach for daily operation and maintenance.

Long-term use is supported by aluminum blades, robust mechanical connections, and integrated safety features. The fan includes a safety cable, hub clips, hub retainer, and dual-method fastening for all joined components.

How This Fixture Is Commonly Used

Once installed, the fan is typically set to run at a speed that matches seasonal requirements. The wall-mounted VFD controller allows you to adjust speed as needed for occupant comfort or process needs.

Operators use the on/off toggle and speed regulator for daily control. The safety disconnect on the controller is used during maintenance or when isolating the fan from power is required.

Aluminum blades and the gear drive motor require minimal ongoing attention. The integrated safety features are designed to reduce risk during both operation and maintenance.

In spaces with fire suppression systems, the integrated sprinkler shut-off is present as part of the fan?s safety design.

Safety, Certifications, and Warranty

The fan includes a safety cable, hub clips, hub retainer, and dual-method fastening for all joined components. An integrated sprinkler shut-off is included for use in spaces with fire suppression systems.

The wall-mounted VFD controller includes a safety disconnect. The fan is covered by a warranty from LED Lighting Supply.

Frequently Asked Questions

What voltages is this fan compatible with?
This fan supports 110V-120V single-phase, 208V-240V single-phase or three-phase, and 460V-480V three-phase power.

What is the maximum coverage area?
The fan is rated for up to 12,750 square feet of coverage.

What mounting options are available?
Mounting options include I-Beam, Z-Purlin, and Open Joist.

What is the warranty coverage?
This fan is covered by a warranty from LED Lighting Supply.

Application Questions and Clarification

This product description reflects the provided specifications, ratings, and configuration options. For questions related to site-specific conditions, electrical compatibility, control integration, or application requirements not addressed in the provided data, our team is available to provide clarification.
