300 / 450 / 600 Watt Adjustable Indirect High Bay Sports Light | 46500 to 93000 Lumens | 5000K | 100-277V
This indirect high bay sports light is a strong choice for facilities needing high-output, efficient illumination with excellent glare control, thanks to selectable wattage (300/450/600W), output up to 93,000 lumens, and a 45° beam via frosted tempered glass optics. Its 200,000-hour lifespan, IK08 impact rating, 6kV surge protection, and UL listing support reliable use in demanding indoor environments. Ideal applications include sports venues, gymnasiums, warehouses, and industrial spaces where uniform, bright lighting and durability are priorities.
Dwayne Kula | President, CTO and Founder
Out of stock
Product Specifications
Key Features
| Brand | LED Lighting Supply |
| Watts | 300 | 450 | 600 |
| Lumens | 46500 | 69750 | 93000 |
| Lumens Per Watt | 155 |
| Replaces | 1000 Watt Metal Halide |
| Voltage | 100V-277V or 277V-480V Optional |
| Color Temperature | 5000K |
| CRI | 80+ |
| Dimming | 0-10V |
| Beam Angles (Std) | 45° |
| Optics | Frosted Tempered Glass |
| Lifespan | 200,000 (L70) hours |
| Mounting | Chain-Cable |
| Mounting (Opt) | Yoke |
| Fixture Color | White |
| Frequency (Hz) | 50/60 |
Durable Construction
| IK Rating | IK08 |
| Surge Protection | 6kV |
| Operating Temperature | -22°F to 122°F |
| Certifications | UL |
| Warranty | 5 years |
Measurements
| Dimensions (in) | 19.25 L X 23.6 W X 6.2 H |
| Weight (lbs) | 17.5 |
Product Lighting Layout Estimator
Use this estimator to calculate approximate fixture count, spacing, and average foot-candles for a simple rectangular space using the selected LED fixture. Enter your room dimensions, mounting height, target foot-candles, light loss factor, and room/layout condition to generate a preliminary lighting layout. When IES photometry is available, workplane height and room reflectance controls are shown.
Project Inputs
Estimated Results
Estimated average foot-candles are preliminary and should be verified with a lighting plan for project-critical applications.
Room / Layout Condition: This field is used only when usable IES photometry is not available. In fallback mode, it acts as a simplified room utilization factor for reflectance, fixture distribution, racking, obstructions, and how much fixture light reaches the work area. Open / light-colored spaces use 0.90, typical warehouses or shops use 0.75, racked or obstructed spaces use 0.60, and dark or complex spaces use 0.45. When IES photometry is active, this field is hidden and the estimator uses the selected workplane height, LLF, and simplified reflectance adjustment instead.
Photometry / Simulation Note: When usable IES photometry is available for the selected fixture, this estimator uses the fixture’s IES candela data, selected workplane height, light loss factor, and simplified reflectance adjustment to estimate fixture count, average foot-candles, and visual light distribution. The reflectance adjustment is a conservative approximation and is not a full zonal-cavity, radiosity, or professional photometric room calculation. When IES photometry is not available, the estimator uses a simulated beam model based on lumens, mounting height, room/layout condition, light loss factor, and beam angle.
Preliminary Estimate Only: This estimator is intended for simple square or rectangular spaces and should be used as a planning aid, not a final photometric lighting plan. Actual light levels may vary based on fixture optics, selected IES file, mounting conditions, workplane height, ceiling height, surface reflectance, obstructions, controls, voltage, installation conditions, and site-specific requirements. Project-critical applications should be verified with a formal lighting plan.
This estimate is a starting point. Warehouses, industrial facilities, hazardous locations, sports areas, schools, healthcare spaces, public areas, and code-sensitive projects may require a reviewed lighting layout before purchase or installation.
Product Overview
This adjustable indirect LED high bay sports light provides 46,500, 69,750, or 93,000 lumens at 5000K. It is built for high-output indoor lighting where a 45 degree beam distribution and frosted tempered-glass optics are needed.
The fixture is commonly used as a 1000 watt metal halide replacement in warehouse lighting, manufacturing facility lighting, and indoor sports facility lighting. Wattage adjustment allows output to be matched to the lighting layout without changing the fixture.
Core Performance and Output
The selectable 300W, 450W, and 600W settings deliver 155 lumens per watt. The standard 45 degree beam angle concentrates output for higher mounting positions and larger open indoor areas.
This fixture operates on 100-277V, with 277-480V available as an option, at 50/60Hz. The 600W setting can create excessive light levels or glare when installed too low, while the 45 degree distribution requires layout review at wider fixture spacing.
Adjustability and Control Options
Field-adjustable wattage provides three output settings: 300W, 450W, and 600W. This supports output adjustment when site conditions, target light levels, or fixture layout requirements change.
0-10V dimming is included for compatible control systems. Voltage selection must match the available electrical supply before installation.
Longevity and Reliability
The LED system is rated for 200,000 hours L70 life. A 6kV surge protection rating supports electrical reliability in commercial and industrial electrical environments.
The fixture is rated for operation from -22F to 122F. Its five-year warranty provides defined coverage for the installed product.
Build Quality and Physical Characteristics
The white fixture housing measures 19.25 inches long by 23.6 inches wide by 6.2 inches high and weighs 17.5 pounds. Frosted tempered glass protects the optical system and softens the visible light source.
An IK08 impact rating supports use in active indoor facilities where incidental contact or impact can occur. Standard chain-cable mounting suspends the fixture from the structure, and yoke mounting is available as an option.
Where This Product Fits Best
This high bay is suited to large indoor spaces that need concentrated output from suspended or yoke-mounted fixtures. The adjustable output supports layouts with different mounting conditions and light-level requirements.
- manufacturing facility lighting
- warehouse lighting
- distribution center lighting
- indoor sports facility lighting
- basketball court lighting
- ice rink lighting
The 45 degree beam angle and high lumen output suit open areas with elevated fixture locations. The -22F to 122F operating range supports indoor spaces with seasonal temperature variation.
Installation and Long-Term Use
Chain-cable mounting requires a suitable overhead support structure and secure suspension hardware. The optional yoke mount changes the mounting method and allows fixture aiming during installation.
Installers should confirm supply voltage, selected wattage, control wiring, fixture weight, and mounting method before energizing the fixture. Long-term maintenance access should account for the fixture location and the need to service mounting and electrical connections.
How This Fixture Is Commonly Used
In warehouse lighting, manufacturing facility lighting, and distribution center lighting, fixtures are normally arranged in rows or grids based on building geometry and work-area lighting requirements. Chain-cable mounting places the fixture below the structural deck, while yoke mounting is used where directional adjustment is required.
For indoor sports facility lighting, basketball court lighting, and ice rink lighting, fixture placement follows the playing-area layout and glare-control requirements. Higher output can reduce fixture count, but the final layout must account for the 45 degree beam distribution and target light levels.
Safety, Certifications, and Warranty
This fixture is UL listed. It has an IK08 impact rating and 6kV surge protection.
The operating temperature range is -22F to 122F. The warranty is five years.
Frequently Asked Questions
Q: What lumen outputs are available?
A: The selectable wattage settings produce 46,500 lumens at 300W, 69,750 lumens at 450W, and 93,000 lumens at 600W.
Q: What beam angle does this high bay use?
A: The standard beam angle is 45 degrees.
Q: Can the fixture be dimmed?
A: Yes. The fixture includes 0-10V dimming.
Q: What mounting methods are available?
A: Chain-cable mounting is standard. Yoke mounting is available as an option.
Q: What voltage does the fixture operate on?
A: Standard operation is 100-277V. A 277-480V option is available.
Application Questions and Clarification
Q: Is this fixture appropriate for warehouse lighting and distribution center lighting?
A: The fixture provides adjustable 300W, 450W, and 600W output settings with a 45 degree beam angle for warehouse lighting and distribution center lighting.
Q: What should be considered for indoor sports facility lighting layouts?
A: Mounting position, target light levels, glare control, and the 45 degree beam distribution affect the layout. A specific spacing value is not established by the supplied product data.
Q: Can the wattage be adjusted after installation?
A: The fixture is wattage adjustable with 300W, 450W, and 600W settings. Wattage selection should be confirmed before final operation.
