200 / 240 / 320 Watt Adjustable LED UFO High Bay | 30000 to 48000 Lumens | 4000K / 5000K Adjustable | 100-277V | Black or White Housing
This adjustable LED UFO high bay is a strong choice for demanding industrial and commercial spaces due to its selectable wattage (200, 240, or 320 watts) and lumen output (30,000 to 48,000 lumens), allowing tailored illumination for various layouts. Its IP65 and IK10 ratings ensure reliable operation in environments exposed to dust, water spray, and physical impacts, while the die-cast aluminum housing and polycarbonate lens support long-term durability. The fixture is ideal for warehouses, manufacturing plants, and distribution centers, but is not intended for hazardous locations or areas lacking adequate mounting support for its 13-pound weight.
Dwayne Kula | President, CTO and Founder
Product Specifications
Key Features
| Brand | LED Lighting Supply |
| Watts | 200 | 240 | 320 |
| Lumens | 30000 | 36000 | 48000 |
| Lumens Per Watt | 150 |
| Replaces | 1000 Watt Metal Halide |
| Voltage | 100V-277V |
| Color Temperature | 4000K or 5000K |
| CRI | 80+ |
| Dimming | 0-10V |
| Beam Angles (Std) | 90° |
| Optics | Polycarbonate Lens |
| Lifespan | 50,000 (L70) hours |
| Mounting | Hook |
| Mounting (Opt) | Pendant or Surface |
| Fixture Color | Black or White |
| Frequency (Hz) | 50/60 |
Durable Construction
| Housing | Die-Cast Aluminum |
| IP Rating | IP65 |
| IK Rating | IK10 |
| Surge Protection | 6kV |
| Operating Temperature | -40°F to 122°F |
| Certifications | UL | DLC Premium |
| Warranty | 5 years |
Measurements
| Dimensions (in) | 13.8 W X 9.5 H |
| Weight (lbs) | 13 |
| Cord Length | 5 Feet |
| Dimming Cord Length | 8 Inches |
Features/Accessories
- Color Adjustable
- Wattage Adjustable
- Motion Sensor
Product SKU Variations
- SKU: LLS-X-HB9-320A-CC
- SKU: LLS-X-HB9-320A-CC-W
Download IES Files
Product Lighting Layout Estimator
Use this estimator to calculate approximate fixture count, spacing, and average foot-candles for a simple rectangular space using the selected LED fixture. Enter your room dimensions, mounting height, target foot-candles, light loss factor, and room/layout condition to generate a preliminary lighting layout. When IES photometry is available, workplane height and room reflectance controls are shown.
Project Inputs
Estimated Results
Estimated average foot-candles are preliminary and should be verified with a lighting plan for project-critical applications.
Room / Layout Condition: This field is used only when usable IES photometry is not available. In fallback mode, it acts as a simplified room utilization factor for reflectance, fixture distribution, racking, obstructions, and how much fixture light reaches the work area. Open / light-colored spaces use 0.90, typical warehouses or shops use 0.75, racked or obstructed spaces use 0.60, and dark or complex spaces use 0.45. When IES photometry is active, this field is hidden and the estimator uses the selected workplane height, LLF, and simplified reflectance adjustment instead.
Photometry / Simulation Note: When usable IES photometry is available for the selected fixture, this estimator uses the fixture’s IES candela data, selected workplane height, light loss factor, and simplified reflectance adjustment to estimate fixture count, average foot-candles, and visual light distribution. The reflectance adjustment is a conservative approximation and is not a full zonal-cavity, radiosity, or professional photometric room calculation. When IES photometry is not available, the estimator uses a simulated beam model based on lumens, mounting height, room/layout condition, light loss factor, and beam angle.
Preliminary Estimate Only: This estimator is intended for simple square or rectangular spaces and should be used as a planning aid, not a final photometric lighting plan. Actual light levels may vary based on fixture optics, selected IES file, mounting conditions, workplane height, ceiling height, surface reflectance, obstructions, controls, voltage, installation conditions, and site-specific requirements. Project-critical applications should be verified with a formal lighting plan.
This estimate is a starting point. Warehouses, industrial facilities, hazardous locations, sports areas, schools, healthcare spaces, public areas, and code-sensitive projects may require a reviewed lighting layout before purchase or installation.
Product Overview
This adjustable LED UFO high bay provides 30,000, 36,000, or 48,000 lumens from selectable 200W, 240W, and 320W settings. It is built for high-ceiling warehouse lighting, manufacturing facility lighting, distribution center lighting, and gymnasium lighting. The compact round fixture uses a die-cast aluminum housing, polycarbonate lens, and 90 degree beam distribution. It can replace a 1000W metal halide fixture where the existing layout and light levels support the conversion. Hook mounting is standard, with pendant and surface mounting available. Black and white housing finishes are available.Core Performance and Output
The fixture produces 150 lumens per watt and operates at 200W, 240W, or 320W. Output is selectable at 30,000, 36,000, or 48,000 lumens, with selectable 4000K and 5000K color temperatures. A 90 degree beam angle provides a broad downward distribution for open high-bay layouts. The 48,000-lumen setting can be excessive at lower mounting heights, while higher mounting heights require layout review to maintain uniformity. Input voltage is 100-277V at 50/60Hz. The fixture has 0-10V dimming capability and 6kV surge protection.Adjustability and Control Options
Wattage and color temperature are adjustable at the fixture. The available settings allow output and color selection to be matched to the installed layout and operating conditions. 0-10V dimming is provided through an 8-inch dimming cord. A motion sensor is available for control operation where sensor-based switching is required.Longevity and Reliability
Rated life is 50,000 hours at L70. The fixture is designed for operation from -40F to 122F. The aluminum housing, polycarbonate lens, IK10 impact rating, and 6kV surge protection support long-term use in demanding high-bay installations. The fixture includes a 5-year warranty.Build Quality and Physical Characteristics
The UFO housing is die-cast aluminum with an IP65 rating and IK10 impact rating. The lens is polycarbonate. Fixture dimensions are 13.8 inches wide by 9.5 inches high, with a weight of 13 pounds. A 5-foot cord is included. Hook mounting is standard. Pendant and surface mounting are optional configurations and should be matched to the available mounting structure.Where This Product Fits Best
This high-output UFO high bay fits large interior spaces with elevated mounting positions and open lighting layouts. Its selectable output supports installations where fixture output may need adjustment during setup or future layout changes.- warehouse lighting
- distribution center lighting
- manufacturing facility lighting
- gymnasium lighting
- aircraft hangar lighting
- indoor sports facility lighting
