25 Watt LED Bollard Light | 3360 Lumens | 5000K | 100-277V | 26 Inches

Product Overview

This 25 Watt LED Bollard Light is designed for ground-mounted pathway and pedestrian area illumination. It delivers a 3360 lumen output at 5000K, providing clear, uniform lighting for outdoor walkways and architectural site features. The fixture stands 26 inches tall and is built for use in commercial, campus, and hospitality environments where controlled, low-glare lighting is required for safety and visual appeal.

The bollard is a direct replacement for 150 Watt metal halide units, offering improved efficiency and reduced maintenance. Typical mounting is along pathways, courtyards, or landscape edges at regular intervals to ensure consistent coverage and visual guidance for pedestrians.

Core Performance and Output

This bollard produces 3360 lumens at 134 lumens per watt, with a 360° distribution for even coverage around the fixture. The 5000K color temperature provides a neutral white light suitable for outdoor visibility and security. Power factor exceeds 0.90, and total harmonic distortion is below 20% for stable electrical performance.

At 26 inches in height, the output is balanced for pathway and pedestrian area use without excessive glare or spill. Excessive spacing between fixtures can result in reduced uniformity and shadowing. Output is not intended for large-area or high-mount applications.

Adjustability and Control Options

This bollard light is a fixed-output fixture with no integrated dimming or motion sensing. The 360° beam angle provides uniform illumination in all directions from the mounting point. No field-adjustable optics or color temperature options are included.

Control integration is possible through external circuit-level controls or timers, but the fixture itself does not include onboard control features.

Longevity and Reliability

The LED system is rated for 70,000 hours of operation, supporting long-term deployment in outdoor environments with minimal maintenance. The die-cast aluminum housing and IP65 rating protect internal components from dust, rain, and incidental water exposure.

Thermal management is passive, with no moving parts or fans. The fixture is designed for continuous operation in typical outdoor temperature ranges encountered in pedestrian and landscape settings.

Build Quality and Physical Characteristics

The housing is constructed from die-cast aluminum with a bronze finish, providing corrosion resistance and impact durability. The fixture measures 26 inches in height and 10.25 inches in diameter, weighing 7 pounds for stable ground mounting.

All wiring and electrical connections are sealed within the housing. The bollard is designed for direct ground mounting using standard anchor bolt patterns. The IP65 enclosure rating ensures protection against rain and dust ingress.

Where This Product Fits Best

This bollard light is intended for outdoor pedestrian environments where low-level, uniform lighting is required for safety and wayfinding. It is suitable for commercial, institutional, and hospitality sites with defined walkways or landscaped areas.

• pathway lighting
• pedestrian area lighting
• architectural site lighting
• landscape lighting
• courtyard lighting
• campus walkway lighting
• hospitality site lighting
• parking area edge lighting

The fixture is suitable for outdoor use in environments exposed to rain, dust, and incidental water. Not intended for high-traffic vehicle areas or locations requiring high-output area lighting.

Installation and Long-Term Use

Installation is ground-mounted using anchor bolts and a secure base plate. The fixture operates on 100-277V input, compatible with standard commercial electrical systems. All wiring is completed within the base, with access provided for connection and maintenance.

Routine inspection is limited to cleaning the exterior and checking for physical damage. No relamping or internal maintenance is required during the rated service life. The bollard is designed for stable operation in outdoor environments with minimal ongoing attention.

How This Fixture Is Commonly Used

Fixtures are typically spaced 10 to 20 feet apart along walkways, paths, or landscape borders, depending on required light levels and site geometry. Mounting height is fixed at 26 inches, providing low-level illumination for pedestrian guidance and safety.

Layout patterns are linear or staggered, following the path or perimeter to ensure continuous coverage. Higher output allows for wider spacing, but excessive distance between fixtures can create dark spots or reduce visual uniformity.

Safety, Certifications, and Warranty

This bollard light is UL listed and IP65 rated. The fixture is eligible for rebate programs where applicable. All electrical and mechanical components are enclosed for user safety during operation and maintenance.

Warranty coverage is provided for defects in materials and workmanship. Refer to documentation for specific warranty terms and conditions.

Frequently Asked Questions

Q: What is the recommended spacing for these bollard lights along a pathway?

A: Typical spacing is 10 to 20 feet, depending on the desired light level and uniformity.

Q: Can this bollard be installed in areas exposed to rain and irrigation?

A: Yes, the IP65 rating protects against rain and incidental water exposure.

Q: Is the fixture compatible with motion sensors or dimming controls?

A: The fixture does not include integrated controls but can be operated on circuits with external sensors or timers.

Q: What is the mounting method for this bollard?

A: The fixture is ground-mounted using anchor bolts and a base plate for secure installation.

Q: Does the bollard require any routine maintenance?

A: Routine maintenance is limited to exterior cleaning and inspection for physical damage.

Application Questions and Clarification

Q: Is this bollard suitable for lighting large parking lots or vehicle drive lanes?

A: No, the output and mounting height are designed for pedestrian areas, not large vehicle zones.

Q: Can this fixture be used for campus walkway lighting in outdoor environments?

A: Yes, campus walkway lighting is a common application for this bollard.

Q: Is the bollard appropriate for hospitality site pathways and courtyards?

A: Yes, it is frequently used in hospitality site pathways, courtyards, and landscaped areas.

Q: What is the maximum mounting height for this fixture?

A: The bollard is designed for a fixed mounting height of 26 inches.
