105 / 135 / 165 Wattage Adjustable LED Linear Vapor Tight Light | 13650 to 21450 Lumens | 3500K / 4000K / 5000K | 100-277V | NSF Rated
This LED linear vapor tight fixture is a strong choice for food processing, storage, and prep areas requiring NSF-rated, shatterproof lighting that withstands frequent high-pressure washdowns. Its selectable wattage (105/135/165W) and color temperature (3500K/4000K/5000K) allow precise adaptation to varying space needs, while the IP69K rating and corrosion-resistant polycarbonate housing ensure durability in wet, chemically cleaned, or temperature-extreme environments. Surface and chain-cable mounting options support installation flexibility. With up to 21,450 lumens and 1-10V dimming, it is well-suited for cold storage, production, and washdown zones, but is not specified for hazardous locations.
Dwayne Kula | President, CTO and Founder
754 in stock
Product Specifications
Key Features
| Brand | LED Lighting Supply |
| Watts | 105 | 135 | 165 |
| Lumens | 13650 | 17550 | 21450 |
| Lumens Per Watt | 130 |
| Replaces | 400 Watt Metal Halide |
| Voltage | 100V-277V |
| Color Temperature | 3500K or 4000K or 5000K |
| CRI | 80+ |
| Dimming | 1-10V |
| Beam Angles (Std) | 120° |
| Optics | Polycarbonate Lens |
| Lifespan | 70,000 hours |
| Mounting | Chain-Cable |
| Mounting (Opt) | Surface |
| Fixture Color | Gray |
| Frequency (Hz) | 50 / 60 hz |
| Power Factor | .93 |
| THD | 20% Max |
Durable Construction
| Housing | Polycarbonate |
| IP Rating | IP69K |
| Operating Temperature | -40°F to 122°F |
| Certifications | UL | DLC Premium | NSF Rated |
| Warranty | 5 years |
Measurements
| Dimensions (in) | 47.2 x 10.4 x 4.1 in |
| Weight (lbs) | 11.25 lbs |
| Cord Length | 3 Feet |
Features/Accessories
- Color Adjustable
- Wattage Adjustable
- Motion Sensor
- NSF Rated Food Grade
Download IES Files
Product Lighting Layout Estimator
Use this estimator to calculate approximate fixture count, spacing, and average foot-candles for a simple rectangular space using the selected LED fixture. Enter your room dimensions, mounting height, target foot-candles, light loss factor, and room/layout condition to generate a preliminary lighting layout. When IES photometry is available, workplane height and room reflectance controls are shown.
Project Inputs
Estimated Results
Estimated average foot-candles are preliminary and should be verified with a lighting plan for project-critical applications.
Room / Layout Condition: This field is used only when usable IES photometry is not available. In fallback mode, it acts as a simplified room utilization factor for reflectance, fixture distribution, racking, obstructions, and how much fixture light reaches the work area. Open / light-colored spaces use 0.90, typical warehouses or shops use 0.75, racked or obstructed spaces use 0.60, and dark or complex spaces use 0.45. When IES photometry is active, this field is hidden and the estimator uses the selected workplane height, LLF, and simplified reflectance adjustment instead.
Photometry / Simulation Note: When usable IES photometry is available for the selected fixture, this estimator uses the fixture’s IES candela data, selected workplane height, light loss factor, and simplified reflectance adjustment to estimate fixture count, average foot-candles, and visual light distribution. The reflectance adjustment is a conservative approximation and is not a full zonal-cavity, radiosity, or professional photometric room calculation. When IES photometry is not available, the estimator uses a simulated beam model based on lumens, mounting height, room/layout condition, light loss factor, and beam angle.
Preliminary Estimate Only: This estimator is intended for simple square or rectangular spaces and should be used as a planning aid, not a final photometric lighting plan. Actual light levels may vary based on fixture optics, selected IES file, mounting conditions, workplane height, ceiling height, surface reflectance, obstructions, controls, voltage, installation conditions, and site-specific requirements. Project-critical applications should be verified with a formal lighting plan.
This estimate is a starting point. Warehouses, industrial facilities, hazardous locations, sports areas, schools, healthcare spaces, public areas, and code-sensitive projects may require a reviewed lighting layout before purchase or installation.
Product Overview
This adjustable LED linear vapor tight light is designed for food-grade lighting environments that require sealed construction, high output, and configurable color and wattage settings. It provides 13,650 to 21,450 lumens across three selectable wattage settings.
The polycarbonate housing and IP69K rating support use in food processing facility lighting, commercial kitchen lighting, and washdown lighting. Chain-cable mounting is standard, with surface mounting available.
Core Performance and Output
The fixture operates at 105W, 135W, or 165W and produces 13,650, 17,550, or 21,450 lumens. Efficacy is 130 lumens per watt, with an 80+ CRI and selectable 3500K, 4000K, or 5000K color temperature.
A 120 degree beam distribution provides broad coverage from the linear fixture body. Higher output can reduce fixture count, but layout must account for glare and uniformity at lower mounting heights.
Adjustability and Control Options
Integrated wattage selection allows the fixture output to be set at 105W, 135W, or 165W. Color temperature selection provides 3500K, 4000K, and 5000K settings.
The fixture supports 1-10V dimming and is available with a motion sensor. It operates on 100-277V, 50/60 Hz power.
Longevity and Reliability
Rated life is 70,000 hours. The driver has a 0.93 power factor and maximum 20% THD.
The operating temperature range is -40F to 122F. The sealed vapor tight construction is suited to environments where moisture exposure and regular cleaning affect fixture selection.
Build Quality and Physical Characteristics
The housing and lens are polycarbonate, with a gray fixture finish. The fixture measures 47.2 x 10.4 x 4.1 inches and weighs 11.25 pounds.
A 3-foot cord is included. Standard mounting is chain-cable, while surface mounting is available for locations where suspended installation is not appropriate.
Where This Product Fits Best
This fixture fits food-grade interior environments requiring high-output linear lighting, sealed construction, and adjustable operating settings. Its NSF rating and IP69K rating align with food processing and washdown conditions.
- food processing facility lighting
- commercial kitchen lighting
- food production lighting
- washdown lighting
- meat processing lighting
- beverage production lighting
- packaging facility lighting
The polycarbonate construction, IP69K rating, and -40F to 122F operating range support locations exposed to moisture, cleaning activity, and cold storage conditions.
Installation and Long-Term Use
Chain-cable mounting supports suspended installation, while optional surface mounting supports direct attachment to a suitable structure. Fixture weight, mounting method, cable routing, and available voltage should be confirmed before installation.
The 100-277V input range supports common commercial electrical systems. Long-term maintenance should include inspection of mounting points, cord condition, lens condition, and sealing surfaces.
How This Fixture Is Commonly Used
In food processing facility lighting and food production lighting layouts, these fixtures are arranged in rows to provide broad distribution from the 120 degree beam angle. Mounting height and target light levels determine the final layout.
Commercial kitchen lighting, washdown lighting, meat processing lighting, beverage production lighting, and packaging facility lighting may use suspended or surface-mounted fixture arrangements based on the available structure. Higher wattage settings increase output, but spacing and fixture placement must be coordinated with the required light level and work area layout.
Safety, Certifications, and Warranty
UL listed. DLC Premium listed. NSF rated.
IP69K rated. The fixture includes a 5-year warranty.
Frequently Asked Questions
Q: What output settings are available?
A: The fixture has selectable 105W, 135W, and 165W settings producing 13,650, 17,550, and 21,450 lumens.
Q: What color temperatures are available?
A: Selectable color temperatures are 3500K, 4000K, and 5000K.
Q: Can this fixture be dimmed?
A: Yes. The fixture supports 1-10V dimming.
Q: What mounting methods are available?
A: Chain-cable mounting is standard. Surface mounting is available.
Q: Is this fixture rated for washdown lighting?
A: The fixture is IP69K rated and NSF rated.
Application Questions and Clarification
Q: What should be reviewed when planning food processing facility lighting layouts?
A: Mounting height, target light levels, fixture wattage setting, color temperature selection, and layout requirements affect fixture placement. Specific spacing values are not established by the supplied product data.
Q: What should be confirmed before selecting surface mounting for commercial kitchen lighting?
A: Confirm that the mounting structure supports the 11.25-pound fixture and that the installation location has suitable 100-277V power.
